DIN X22CrNiMoV12-1 X22CrMoV12-1 Turbine Blade Steel For Construction
DIN X22CrNiMoV12-1 X22CrMoV12-1 Turbine Blade Steel X22CrMoV12-1 Round Bar Flat Bar
Description
Our company provides DIN X22CrNiMoV12-1 X22CrMoV12-1 Machined Turbine Blade Steel X22CrMoV12-1 Solution treated Quenched and Tempered Round Bar X22CrNiMoV12-1 Flat Bar.All of DIN X22CrNiMoV12-1 X22CrMoV12-1 Machined Turbine Blade Steel X22CrMoV12-1 Solution treated Quenched and Tempered Round Bar X22CrNiMoV12-1 Flat Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,DIN X22CrNiMoV12-1 X22CrMoV12-1 Turbine Blade Steel X22CrMoV12-1 Round Bar X22CrNiMoV12-1 Flat Bar.
Products Details
DIN X22CrNiMoV12-1 X22CrMoV12-1 Machined Turbine Blade Steel X22CrMoV12-1 Solution treated Quenched and Tempered Round Bar X22CrNiMoV12-1 Flat Bar.
| Chemical Composition (weight%): | C (％): 0.18 ~ 0.24 |
| Si (％): 0.18 ~ 0.24 | |
| Mn (％): 0.40 ~ 0.90 | |
| P (％)≤: 0.025 | |
| S (％)≤: 0.015 | |
| Cr (％): 11.0 ~ 12.5 | |
| Ni (％): 0.30 ~ 0.80 | |
| Mo (％): 0.80 ~ 1.20 | |
| V (％): 0.25 ~ 0.35 | |
| Mechanical Properties Under Final Heat Treatment: |
Condition: heat treatment |
| Tensile strength, σb/MPa: 800 ~ 950 | |
| Yield strength, σs≥/MPa: 600 | |
| Elongation, δ5≥(％): 14.0 | |
| Non-scale temperature in Air: 600℃ |
Applications:
X22CrNiMoV12-1 Turbine Blade Steel X22 Round Bar 1.4923 1.4934 Flat Bar X22CrMoV12-1 TLV 9248 06 Bar.
Heat-resistant steel is widely used in the field of manufacturing the boiler, steam turbine, motive power machine, industrial furnace, and other mechanical parts of aviation, petrochemical engineering operating at high temperature. Those parts must hold the features: high temperature strength, resistance to high temperature oxide etch, enough toughness, excellent machinability, weldability, structure stability based on different usages.
Equivalent Grade:
DIN X22CrNiMoV12-1
X22CrMoV12-1
DIN X22CrNiMoV12-1 X22CrMoV12-1 Machined Turbine Blade Steel X22CrMoV12-1 Solution treated Quenched and Tempered Round Bar X22CrNiMoV12-1 Flat Bar.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of DIN X22CrNiMoV12-1 X22CrMoV12-1 Turbine Blade Steel X22CrMoV12-1 Round Bar X22CrNiMoV12-1 Flat Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
