Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545
X5CrNiCu15-5 1.4545 Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Flat Bar
Description
Our company provides X5CrNiCu15-5 1.4545 Annealed / Quenched and Tempered Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Milled / Cold working / Machined Flat Bar.
All of X5CrNiCu15-5 1.4545 Annealed / Quenched and Tempered Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Milled / Cold working / Machined Flat Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
X5CrNiCu15-5 1.4545 Annealed / Quenched and Tempered Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Milled / Cold working / Machined Flat Bar.
| Chemical Composition (weight%): | |
| C | ≤ 0.07 |
| Si | ≤ 1.00 |
| Mn | ≤ 1.00 |
| P | ≤ 0.040 |
| S | ≤ 0.030 |
| Cr | 14.0 ~ 15.5 |
| Ni | 3.50 ~ 5.50 |
| Mo | - |
| Cu | 2.50 ~ 4.50 |
| Nb+Ta | 0.15 ~ 0.45 |
| Mechanical Properties Under Final Heat Treatment: | |
| Form: Bar, forge piece Condition: H900 | |
| Tensile strength, σb/MPa | 1310 |
| Yield strength, σ0.2/MPa | 1170 |
| Elongation, δ (％) | 35 |
| Harndess: HRC | 40 |
| Form: Bar, forge piece Condition: H925 | |
| σb/MPa | 1170 |
| σ0.2/MPa | 1070 |
| δ (％) | L-10.0 |
| ψ (％) | L-38.0 |
| Hardness HRC |
38 |
|
Form: Bar, forge piece Condition: H1025 |
|
| σb/MPa | 1070 |
| σ0.2/MPa | 1000 |
| δ (％) | 12.0 |
| ψ (％) | 45 |
| Hardness HRC | 35 |
| Form: Bar, forge piece Condition: H1075 | |
| σb/MPa | 1000 |
| σ0.2/MPa | 860 |
| δ (％) | 13.0 |
| ψ (％) | 45.0 |
| Hardness HRC | 32 |
| Form: Bar, forge piece Condition: H1100 | |
| σb/MPa | 965 |
| σ0.2/MPa | 795 |
| δ(％) | 14；10 |
| ψ(％) | 45；29 |
| Hardness HRC | 31 |
Equivalent Grade:
X5CrNiCu15-5
1.4545
X5CrNiCu15-5 1.4545 Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Flat Bar
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of X5CrNiCu15-5 1.4545 Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Flat Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
