Inconel 721 Alloy Steel Plate Corrosion Resistance For Engineering
Inconel alloy 721 Alloy Steel Plates Inconel 721 Alloy Plates Inconel 721 Alloy
Description
Our company provides Inconel alloy 721 Black Alloy Steel Plates Inconel 721 Bright Alloy Plates Inconel 721 Rrough Turned Alloy.
All of Inconel alloy 721 Black Alloy Steel Plates Inconel 721 Bright Alloy Plates Inconel 721 Rrough Turned Alloy conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Inconel alloy 721 Alloy Steel Plates Inconel 721 Alloy Plates Inconel 721 Alloy
-
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
- Length: Fixed length or random length or based on the customer's special requirement.
-
Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
-
Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
Products Details
Inconel alloy 721 Black Alloy Steel Plates Inconel 721 Bright Alloy Plates Inconel 721 Rrough Turned Alloy
| Chemical Composition (weight%): | C (％): ≤ 0.07 |
| Si (％): ≤ 0.15 | |
| Mn(％):2.00 ~ 2.50 | |
| P(％): ≤ 0.015 | |
| S (％): ≤0.010 | |
| Cr (％): 15.0 ~ 17.0 | |
| Ni (％): Remainder | |
|
Al (%): ≤ 0.10 |
|
| Cu: (%): ≤ 0.20 | |
| Ti (%): 2.75 ~ 3.35 | |
| Fe (%): ≤ 8.0 | |
| Mechanical Properties Under Final Heat Treatment: |
Tensile strength, σb/≥ MPa: 660 |
|
Yield strength, σ0.2/MPa: 290 |
|
| Elongation, δ ≥(％): 55.0 | |
| Reduction of area, ф ≥ (％): - | |
| Hardness via heat treatment /HBW: HV146 |
Applications:
Inconel alloy 721 Black Alloy Steel Plates Inconel 721 Bright Alloy Plates Inconel 721 Rrough Turned Alloy
Turbine engine parts - mechanical gears, gear shaft, main axis, blade
Mechanical parts - bolt and nut, fastener
Gas turbine blade
aerospace craft
rocket motor
nuclear reactor
Fuel nozzle,etc
Inconel alloy 721 Black Alloy Steel Plates Inconel 721 Bright Alloy Plates Inconel 721 Rrough Turned Alloy
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of Inconel Inconel alloy 721 Black Alloy Steel Plates Inconel 721 Bright Alloy Plates Inconel 721 Rrough Turned Alloy and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
Packing method
Wooden Pallet BOX,Standard Seaworthy Package,based on the customer's special requirement,etc
