Description
UNS S35500 Stainless Steel Flat Bar AM-355 AISI 634 Bar is a molybdenum-chromium-nickel steel that can be heat treated by precipitation hardening. AISI 634 Stainless Steel Flat Bar can be used in aerospace applications that withstand high temperatures. AISI 634 Stainless Steel Flat Bar has excellent corrosion resistance, especially compared to other martensitic stainless grades. AISI 634 Stainless Steel Flat Bar responds well to both hot and cold working.
All of UNS S35500 Stainless Steel Flat Bar AM-355 AISI 634 Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Stainless Steel Flat Bar,AM-355, AISI 634, UNS S35500
- Shape:Stainless Steel Flat Bar.
- Square bar / Flat bar: 3mm to 800mm.
Products Details
| Chemical Composition (weight%): | C(％): 0.10 ~ 0.15 |
| Si (％): ≤ 0.50 | |
| Mn (％): 0.50 ~ 1.25 | |
| P(％):≤ 0.025 | |
| S (％):≤ 0.010 | |
| Cr (％): 15.0 ~ 16.0 | |
| Ni (％): 4.00 ~ 5.00 | |
| Mo (％): 2.50 ~ 3.20 | |
| N (％): - | |
| Nb + Ta (%): 0.15 ~ 0.50 | |
| Mechanical Properties Under Final Heat Treatment: |
Condition: annealing |
| Tensile strength, σb/MPa: ≤1380 | |
| Yield strength, σ0.2/MPa: 585~620 | |
| Elongation, δ(％): 8~12 | |
| Reduction of area, ф(％): - | |
|
Form: plate,sheet,strip Condition: H850 |
|
| TS, σb/MPa: 1175 | |
| YS, σ0.2/MPa: 1030 | |
| E, δ(％): 2~8 | |
|
Form: plate,sheet,strip Condition: H1000 |
|
| TS, σb/MPa: 1140 | |
| YS, σ0.2/MPa: 1000 | |
| E, δ(％): 2~8 | |
| A, ф(％): - |
Applications:
| UNS S35500 Stainless Steel Flat Bar AM-355 AISI 634 Bar used most often in the Blades, Gas Turbines, Rotors, etc. |
Equivalent Grade
AM-355, AISI 634, UNS S35500
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of UNS S35500 Stainless Steel Flat Bar AM-355 AISI 634 Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
