DIN EN X8Ni9 Structural Steel Plates W-Nr 1.5662
DIN EN X8Ni9 Structural Steel Plates W-Nr 1.5662
Description
The nickel-alloyed cryogenic material DIN EN X8Ni9 Structural Steel Plates, materia number W-Nr 1.5662 is used in pressure vessel construction.
All of DIN EN X8Ni9 Structural Steel Plates W-Nr 1.5662 conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Structural Steel Plates, DIN EN X8Ni9 Structural Steel Plates W-Nr 1.5662
- Shape:Structural Steel Plates
- Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
- Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
Products Details
DIN EN X8Ni9 Structural Steel Plates W-Nr 1.5662
| Chemical Composition (weight%): | C | ≤0.10 | Mechanical Properties Under Final Heat Treatment: | Elongation: | 18 % |
| Si | ≤0.35 | Elongation, transverse: | 16 % | ||
| Mn | 0.30～0.80 | Tensile strength: | 640 - 840 MPa | ||
| P | 0.020 | Tensile strength, transverse : | 640 - 840 MPa | ||
| S | 0.010 | Yield strength: | 480 - 490 MPa | ||
|
Cr |
- | Yield strength, transverse: | 480 - 490 MPa | ||
| Ni | 8.50～10.0 | ||||
| Other: | Mo≤0.10,V(％): ≤0.05, Cr+Cu+Mo≤0.50％ |
Applications:
DIN EN X8Ni9 Structural Steel Plates W-Nr 1.5662 Application for refrigerators, gearbox parts and components in machine and apparatus engineering which are exposed to temperatures up to -200 °C.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
