FV520B Stainless Steel Round Bar
FV520B Stainless Steel Round Bar
Description
FV520B Stainless Steel Round Bar Primary applications are for parts and accessories that require corrosion resistance, high strength, and good ductility.
All of FV520B Stainless Steel Round Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
- Material:Metal,Stainless Steel Round Bar, FV520B
- Shape:Stainless Steel Round Bar
- Round bar / Wire rod (Diameter): 5.5mm to 800mm
- Square bar / Flat bar: 3mm to 800mm
- Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
- Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
- Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm
Products Details
FV520B Stainless Steel Round Bar
| Chemical Composition (weight%): | Mechanical Properties Under Final Heat Treatment: |
|
C (％): ≤ 0.07
Si (％): ≤ 0.70 Mn (％): ≤ 1.00 P (％)≤: 0.035 S (％)≤: 0.025 Cr (％): 13.0 ~ 15.0 Ni (％): 5.00 ~ 6.50 Mo (％): 1.20 ~ 2.00 Other (％): Cu 1.20 ~ 2.00, Nb 0.20 ~ 0.70 |
Form: Round bar
Condition: double overaged,1050º C +2 hours 750-850 ºC,+2 hours 750-850 ºC Proof stress (N/mm²): 800 Tensile strength, σb/MPa: 925 ~ 1035 Yield strength, σ0.2/MPa: 775 Elongation, δ (％): 15.0 Hardness | HB: 277 ~ 341 Impact strength, AKv /Min: 54 |
Applications:
FV520B Stainless Steel Round Bar is often used in the pump shafts, impellers, fasteners, valves, hydraulic equipment used in oil and gas industries, marine and nuclear engineering, and aircraft components such as steam turbine blades.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
