The Mitsubishi Electric general-purpose AC servo MELSERVO-JE series have limited functions with keeping

high performance based on MELSERVO-J4 series.

The servo amplifier has position, speed, and torque control modes. In the position control mode, the

maximum pulse train of 4 Mpulses/s is supported. Further, it can perform operation with the control modes

switched, e.g. position/speed control, speed/torque control and torque/position control. Hence, it is

applicable to a wide range of fields, not only precision positioning and smooth speed control of machine tools

and general industrial machines but also line control and tension control.

With one-touch tuning and real-time auto tuning, you can automatically adjust the servo gains according to

the machine.

The tough drive function, drive recorder function, and preventive maintenance support function strongly

support machine maintenance.

The servo amplifier has a USB communication interface. Therefore, you can connect the servo amplifier to

the personal computer with MR Configurator2 installed to perform the parameter setting, test operation, gain

adjustment, and others.

The MELSERVO-JE series servo motor equipped with an incremental encoder whose resolution is 131072

pulses/rev will enable a high-accuracy positioning.
