Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM MP22
Price:
$1,499.00 - $1,699.00/Pieces
MOQ:
1pc
Delivery Time:
about 10 days
Brand:
SUCE
Product Description
Mars K series ctg machine maternal and fetal doppler monitor for TOCO,FHR,FM
Product Description
Introduction
The MP22 Series high-tech fetal monitor offers a reliable, high-performance solution for fetal monitoring needs in doctors’ practices, clinics and hospitals, from pre-natal check-ups to antepartum monitoring of high-risk pregnancies.
An optional USB Mouse/Keyboard control eases navigation and data entry.
An optional Non-Stress Test (NST) report software eases documentation in antepartum monitoring.
An optional USB Mouse/Keyboard control eases navigation and data entry.
An optional Non-Stress Test (NST) report software eases documentation in antepartum monitoring.
|
Standerd parameters:
|
TOCO,FHR,FM
|
|
Option:
|
twin montiroing,FAS(Fetal acoustic simulator)
|
|
|
Transducer: Multi-crystals, wide wave beam, pulsed-wave working method, high sensitivity
|
|
|
Strength: < 5mW/cm2
|
|
RESP
|
Working Frequency: 1.0MHz
|
|
|
Signal Processing: Special DSP system and modern recognition
|
|
Alarm Range: High Limit: 160, 170, 180, 190 bpmSpO2
|
Measurement Range:50～240bpm
|
|
|
Alarm Range: High Limit: 160, 170, 180, 190 bpm Low Limit: 90, 100, 110, 120 bpm
|
|
NIBP
|
Maximum Audio Output Power: 1.5 Watt
|
|
TOCO
|
Measurement Range: 0-100 units
|
|
Display
|
Type: 12.1″, color TFT LCD - Resolution: 800×600 pixels
|
|
Gel
|
Viscous aqueous non-sensitizing, hypo-allergenic and non-irritating to skin. Bacteriostat (not sterile)
|
|
Size and Weight:
|
Type: 12.1″, color TFT LCD - Resolution: 800×600 pixels
|
Recorder - Recording speed: Real-time recording : 1cm/min, 2cm/min, 3cm/min Review of fast recording: up to 13mm/s - Paper type: 152 mm Z-folded thermosensitive printing paper FHR - Measurement method: Ultrasound Pulsed Doppler - Ultrasonic intensity: < 5mW/cm2 - Ultrasonic frequency: 1.0MHz, deviation less than ±10％ - FHR Measurement Range: 50bpm ~ 210bpm - Resolution: 1bpm - Accuracy: ±2bpm - Output beam intensity(Iob): <20mW/cm2 TOCO - Measurement method: Strain Gauge Sensor Element - Measurement range: 0~100 units (relative to %) - Resolution: 1% (1 unit) - Nonlinear accuracy: ≤ ±10% - TOCO baseline: 0, 5, 10, 15, 20 ,optional
FM - Measurement method: Doppler ultrasound - FM intensity measurement range: 0-40 (%) relative range - Resolution: 1％ - Model: Auto/Manual NIBP - Measurement way: Automatic oscillometry - Measurement mode: Manual , Auto - Intervals for Auto measurement time: 3 min, 5 min, 10 min, 15 min, 30 min, 60 min, 90min, 2h, 4h - Measurement kinds(Adult): Sys, Dia, Map - Measurement range (mmHg): SpO2 - Measurement range: 0% to 100% - Alarm range: High/low limit: 85% to 100% - Resolution: 1% - Accuracy: 70% to 100%: ± 2% 35% to 69%: ±3% 0% to 34%: undefined
