LiFePO4 Lithium Battery 48V 72V OEM ODM 80AH 150AH 200AH 280AH 350AH 400AH Lithium Ion Golf Cart / Forklift Battery

Price Negotiable
Price: Negotiable
MOQ: 10-1000 units
Delivery Time: 7-15 working days
Brand: CLTF
Product Description
48V 72V 96V 150AH 200AH 300AH 400AH Energy Storage Lifepo4 Lithium Battery Pack

If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.

Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.

Electrical
Characteristics
Nominal Voltage
12.8V
Nominal Capacity
150Ah@0.2C
Energy
1920Wh
Internal Resistance
≤40mΩ
Cycle Life
2000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity
Self Discharge
≤3.5% per month at 25℃
Standard Charging
Max.Charging Voltage
14.0~14.6V
Charging Mode
At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C
Charging Current
75A
Max.Charging Current
100A
Standard Discharging
Discharging Current
75A
Max. Continuous Current
100A
Max.Pulse Current
200A(<3S)
Discharging Cut-off Voltage
10.0
Operating Condition
Charge Temperature
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Discharge Temperature
-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
Storage Temperature
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Water Dust Resistance
IP55
Structure
Cell & Format
IFR32700 N60,4S25P
Casing
Plastic
Dimension(L*W*H*TH)
485*170*240*240
Weight
Approx. 17.5Kg
Terminal
M8
Feature
  • Using the technology of lithium iron phosphate cell, superior safety, thousands of cycles, 100%DOD, under normal conditions.
  • Built-in automatic protection for over-charge, over-discharge, over current, and over temperature.
  • Free of maintenance.
  • Internal cell balancing.
  • Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.
  • Can be charged using most standard lead-acid charges (set).
  • Wider temperature range:-20℃~60℃.
  • Support for Series application expansion (up to 51.2V) and two in parallels.
Product Application:

Products are widely used in hybrid wind off-grid power stations, household energy storage power generation systems, monitoring systems, equipment, street lamp, outdoors, electric cars, electric sightseeing cars, street cleaners, sanitation trucks, the uninterrupted power source(UPS), communication base station, and emergency EPS system, etc. The company has advanced manufacturing equipment, manufacturing technique, and detection technology, especially with the manufacturing technology of nano-silicon colloid electrolytes.

FAQ
  1. Q1: Is this 60V 58Ah battery suitable for my electric tricycle?
    A1: Yes, it fits most 60V electric tricycle systems. Please confirm your vehicle voltage before purchase to avoid incompatibility.
  2. Q2: What is the cycle life of this battery?
    A2: It can support more than 1500 charge-discharge cycles. Under normal use, it can meet long-term use needs and greatly reduce the replacement frequency.
  3. Q3: Does the battery come with BMS protection?
    A3: Yes, built-in smart BMS provides full safety protection against overcharge, over-discharge, over-current and short circuit.
  4. Q4: What is the charging time?
    A4: With a standard charger, it takes about 6-8 hours to fully charge; if using a fast charger, the charging time can be appropriately shortened (subject to charger parameters).
  5. Q5: Can I customize the size or connector of the battery?
    A5: Yes, we accept customized dimensions, connector types and wiring methods, which can be personalized according to your specific needs.
  6. Q6: What is the operating temperature range of the battery?
    A6: It works stably from -20℃ to 60℃, which can work stably under different climate conditions such as cold and hot, suitable for use in different regions.
  7. Q7: What is the weight of the battery?
    A7: It is the weight of the standard version. The specific weight can be adjusted according to customized needs. For detailed weight parameters, please contact customer service for consultation.
