LiFePO4 Lithium Battery Home Solar Energy Storage 48V 5Kwh 7Kwh 10Kwh 100Ah 200Ah
OEM ODM 48V 100AH 200AH Energy Power Storage Lifepo4 Lithium Battery Pack
If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.
Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
| MODEL | CLTF-0242 |
| ELECTRICAL SPECIFICATIONS | |
| Cell Type - Chemistry | Prismatic- LiFePO4 |
| Rated Capacity | 100Ah |
| Rated Voltage | 51.2V |
| Energy | 5120Wh |
| Resistance | 30mΩ |
| Self Discharge | <1.5% per month |
| Maximum Modules in Parallel | 12 |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 720*445*220mm |
| Weight | 60Kg |
| Enclosure Protection | IP65 |
| DISCHARGE/CHARGE SPECIFICATIONS | |
| Discharge Cut-off Voltage | 48V |
| Max Continuous Discharging Current | 100A |
| Peak Discharge Current | 150A for 3 seconds |
| Recommended Discharge Current | 50A |
| CHARGE SPECIFICATIONS | |
| Charging Limited Voltage | 57.6V |
| Max Charging Current | 50A |
| Recommended Charge Current | 25A |
| TEMPERATURE SPECIFICATIONS | |
| Charge Temperature Range | 0~45℃ |
| Discharge Temperature Range | -20~60℃ |
| Recommended Operating Temperature | 15~35℃ |
|
Storage Temperature & Humidity Range (Less than 1 month) |
-20~35℃, 45~75%RH |
|
Storage Temperature & Humidity Range (Less than 3 months) |
-10~35℃, 45~75%RH |
| Recommended Storage Temperature & Humidity Range | 15~35℃, 45~75%RH |
Features:
1. Most safe LFP battery technology, no cobalt.
2. Long lifetimes - >5000 cycles @85% DOD.
3. Easily expandable 5kWh Standard modules - up to 60kWh.
4. Standard module capacity can be customized.
5. Self-engineered BMS with cell level monitor.
6. Short circuit/ Over current/Over voltage/Over temperature protection.
7. Bluetooth APP available on request to see the status of the battery.
8. Strong steel case with white color(optional).
9. Canbus communication access.
10. IP65 waterproof.
11. OEM logo available.
To Pack Wall-Mounted Lithium Ion Battery well. Generally, as follow:
2) Packaging also can be made by customers requirements
