CLF OEM ODM 51.2V 50ah LiFePO4 Lithium Iron Battery Packs Power Battery for electric golf carts Marine Boats Car

CLF 24V 25.6v 20ah OEM ODM Electric Tools LiFePO4  Lithium Iron Battery Packs

Product Parameter

Cell type: LF105/52Ah/3.2V

Battery specifications: LF105-16S1P/50Ah/51.2V

Nominal voltage: 51.2V

Nominal capacity: 50.0Ah

Charging voltage: 58.4V

Charging current: ≤25.0A

Discharge current: 50.0A

Instant discharge current: 70A

Discharge cut-off voltage: 40.0V

Internal resistance of finished product: ≤100mΩ

Battery weight: ≤28.0kg

Product size: 230*310*410mm

Charging temperature: 0 ~ 55℃

Discharge temperature: -20 ~ 55℃

Storage temperature: -20 ~ 45℃

Battery case: sheet metal case

Intelligent lithium protection: power management (RS485,CAN protocol), short circuit protection, over charge protection, over discharge protection, over current protection, over temperature protection, etc

Application fields: golf cart, robot, UPS, lawn mower, etc

Product Features

Low power consumption;

The battery has built-in temperature protection,

Battery pack safety, long cycle life;

Tape 485 communication

High cycle life of battery pack, in line with low carbon, energy saving, environmental protection value concept;

Production Details

From the battery cell to the battery pack, CLF controls every production link in strict accordance with the ISO9001 standard, arranges quality inspectors to check the process details to ensure the safety of the battery, and presents the best products to every customer.
