LiFePO4 Stackable 10kwh Lithium Ion Battery Pack 48v 200Ah 10KWH 15KWH 20KWH For Solar Energy Storage System 6000cycles

Price Negotiable
Price: Negotiable
MOQ: 1 unit
Delivery Time: 7-15 working days
Brand: OEM
Product Description

Powerwall Home Power Battery 10kwh Lithium Ion Battery 48v 200Ah For Solar Storage

Model
CLF-2800
CLF-10K
Capacity Energy
2.8kWh
11.2kWh
Capacity Ah
55Ah
220Ah
Suggested SOC
10~100%
Usable Capacity
2.6kWh
10.4kWh
Nominal Voltage
51.2V
Operation Voltage
44.8V – 57.6V
Maximum Charging/ Discharging Current
35A/50A
100A/100A per stack
Life Cycling (0.5C 25℃)
6000 cycles @ 0.5C
BMS
Parallel function, single cell voltage and temperature measurement, protections, display optional, heating function optional
Communication
CAN, RS485
Scalable
Yes, maximum 15 packs
Design Lifespan
more than 10 years
Operation Temperature
Chrage : 0 ~ 45℃, Dischrage : -20 ~ 45℃
Storage Temperature
-20 ~ 45℃
Weight
30kG
120kG
Dimensions
480x280x210mm
480x280x900 mm
Certifications
MSDS, UN38.3, RoHS, IEC62619, UL, CE
IP Grade
IP54
Warranty
10 years



Product Quality
1, The cell is fixed with screws and fireproof tape to make the battery cell more stable

2, Two layers of fireproof sponges prevent collisions during transportation.

3, All wires are well protected to prevent any risk of short circut

LiFePO4 BATTERY CELL


Product Packaging
To Pack Wall-Mounted Lithium Ion Battery well. Generally, as follow:

1) Inner box - Carton - Pallet- Container

2) Packaging also can be made by customers requirements
