OEM ODM LiFePO4 lithium battery 24100 24v 200ah Lifepo4 Battery Customized battery lithium battery packs
OEM ODM LiFePO4 lithium battery 24100 24v 200ah Lifepo4 Battery Customized battery lithium battery packs
If you don't see any products that are matching your requirements please contact us. We may not have it listed on our website yet.
Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
| Mechanical | Cell & Method | Lifepo4 |
| Dimension(L*W*H) | 580*292*157 mm | |
| Weight | 20KG | |
| Electrical Characteristics | Rated Capacity | 100Ah |
| High Rate Discharge Capacity | > 90% Rated Capacity | |
| Discharge Capacity @ -20ºC(-4ºF) | > 70% Rated Capacity | |
| Norminal Voltage | 24V | |
| Energy | 2400Wh | |
| Internal Impedance(@ 1000Hz.) | ≤20 mΩ | |
| Cycle Life | >2500 Cycles @ 1C 100% DOD | |
| Months Self Discharge | ≤ 5% @ 25ºC(77ºF) | |
| Efficiency of Charge | 100% @ 1/3C | |
| Efficiency of Disharge | 95% @1C | |
|
Standard Disharge |
Max Charge Voltage | 29.2V |
| Charge Current | 100A | |
| Max Charge Current | 100A | |
| Environmental | Charge Temperature | 0 ºC to 45ºC(32ºF to 113ºF) @ 65±20%Relative Humidity |
| Discharge Temperature | -20ºC to 60ºC(-4ºF to 140ºF) @ 65±20%Relative Humidity | |
| Storage Temperature | ≤ 1 Month, -20ºC to 60ºC(-4ºF to 140ºF) @ 65±20%Relative Humidity | |
| ≤ 6 Month, -20ºC to 30ºC(-4ºF to 80ºF) @ 65±20%Relative Humidity |
Pictures:
Features:
1. Long lifespan >2500 cycles.
2. Small size with light weight.
3. Most safe lifepo4 battery with car level standard.
4. In-built samrt BMS with multiprotection.
5. Modular and quick plug design makes it easy to use.
