Tesla Powerwall Solar Home Lithium Battery Pack 5kwh 6000 Cycles Life Solar Storage System lifepo4 lithium battery
6000 Cycles Life Tesla Powerwall Solar Home Battery 5kwh Power Wall Lithium Battery Pack
Specifications:
| MODEL | CLTF-0233 |
| ELECTRICAL SPECIFICATIONS | |
| Cell Type - Chemistry | Prismatic- LiFePO4 |
| Rated Capacity | 100Ah |
| Rated Voltage | 51.2V |
| Energy | 5120Wh |
| Resistance | 30mΩ |
| Self Discharge | <1.5% per month |
| Maximum Modules in Parallel | 12 |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 720*445*220mm |
| Weight | 60Kg |
| Enclosure Protection | IP65 |
| DISCHARGE/CHARGE SPECIFICATIONS | |
| Discharge Cut-off Voltage | 48V |
| Max Continuous Discharging Current | 100A |
| Peak Discharge Current | 150A for 3 seconds |
| Recommended Discharge Current | 50A |
| CHARGE SPECIFICATIONS | |
| Charging Limited Voltage | 57.6V |
| Max Charging Current | 50A |
| Recommended Charge Current | 25A |
| TEMPERATURE SPECIFICATIONS | |
| Charge Temperature Range | 0~45℃ |
| Discharge Temperature Range | -20~60℃ |
| Recommended Operating Temperature | 15~35℃ |
|
Storage Temperature & Humidity Range (Less than 1 month) |
-20~35℃, 45~75%RH |
|
Storage Temperature & Humidity Range (Less than 3 months) |
-10~35℃, 45~75%RH |
| Recommended Storage Temperature & Humidity Range |
15~35℃, 45~75%RH |
1. Most safe LFP battery technology, no cobalt.
2. Long lifetimes - >5000 cycles @85% DOD.
3. Easily expandable 5kWh Standard modules - up to 60kWh.
4. Standard module capacity can be customized.
5. Self-engineered BMS with cell level monitor.
6. Short circuit/ Over current/Over voltage/Over temperature protection.
7. Bluetooth APP available on request to see the status of the battery.
8. Strong steel case with white color(optional).
9. Canbus communication access.
