Powerwall 100Ah 5KW Lifepo4 Rechargeable Battery Wall Mounted For Solar Power System

Price Negotiable

Price: Negotiable

MOQ: 10 units

Delivery Time: 7-15 working days

Brand: CLF

Product Description

Rechargeable Lifepo4 Powerwall 100Ah 5KW Lifepo4 Storage Battery For Solar Wall Mounted Power System

Electrical Performance

Nominal Voltage	51.2V
Nominal Capacity	100Ah
Energy	5120Wh
Communication	CAN/RS232/RS485
Resistance	≤50mΩ@50%SOC
Efficiency	>96%
Module Parallel	Up to 16packs

Charge Performance:

Recommended ChargeCurrent	20A
Maximum Charge Current	50A
Recommended Charge Voltage	57.6V
BMS Charge Cut-Off Voltage	58.4V(3.65V/Cell)
Reconnect Voltage	>53.6V(3.35V/Cell)
Balancing Starting Voltage	3.4V/Cell

Discharge Performance:

Maximum Continuous Discharge Current	100A
Peak Discharge Current	110A(1s)
BMS Discharge Cut-Off Current	150A(100ms)
Recommended Low Voltage Disconnect	48V(3.0V/Cell)
BMS Discharge Cut-Off Voltage	43.2V(1s)(2.7V/Cell)
Reconnect Voltage	>48V(3V/Cell)
Short Circuit Protection	<350μs

Mechanical Performance

Dimension(LxWxH)	580460150mm 22.83x18.11x5.90"
Approx.Weight	~110Ibs(50Kg)
Terminal Type	Quick connector
Terminal Torque	80~100in-Ibs(9~11N-m)
Case Material	SPCC
Enclosure Protection	IP54

Temperature Performance

Discharge Temperature	-4~140°F(-20~60°℃)
Charge Temperature	32~113°F(0~45℃)
Storage Temperature	23~95°F(-5~35℃)
BMS High Temperature Cut-Off	149°F(65℃)
Reconnect Temperature	131°F(55°℃)

Features:

1. High Energy: 5KWh energy storage, can meet 1 day electricity usage of Home.

2. Bank-up function: no need worry of out of electricity when any emergency situation.

3. Solar system. can work with Solar panels to storage Solar energy. save money and eco friendly

4. Save electricity fee. can adjust electricity usage when high price, and save more money.

5. Long service life: Lifepo4 battery Prismatic cell, can service 3000 times when left 80% energy, that is mean can service 10~15 years when High frequency of use.

6. Safe. Lifepo4 battery has no possibility of explosion when any usage condition, it is very safe to place it in house.

7. Save space . Wall mounted design, don't take up space.
