10W Picosecond IR Laser All In One Design Brittle Material Processing
10W Picosecond IR Laser number of offices in east and south China. So far, Tianjin BWT Laser Ltd. has several products lines, including 10 to 100 watts of picosecond IR laser (energy up to 2mJ), femtosecond IR laser with 50W 50uJ output, 10 W femtosecond laser with narrow pulse width, and 30W picosecond UV laser etc. These lasers have been widely used in various fields such as industrial micro-processing, precision marking, medical treatment, scientific research and many other applications.
Features:
Power:>10W@100KHz
Max Energy:>100μJ@100KHz
Pulse Width:<15ps
High Beam Quality
Compact Design
Stable output power and pulse energy
Applications:
Thin glass, Ceramic, Sapphire etc cutting and hole drilling
Sapphire wafer Stealth laser dicing
Precision Laser Marking
Laser ablation of electrodes layer for Li-ion battery
Metallic parts precision processing
| Parameters | Unit | BGL-1064-10B | |||
| Minimum | Typical | Maximum | |||
| Optical Data | Power | W | 10 | - | - |
| Wavelength | nm | 1064 | |||
| Repetition frequency | khz | 10 | 100 | z1000 | |
| Pulse Width | ps | - | - | 15 | |
| Average Power | w | 10W@100kHz | |||
| Maximum Pulse Energy | mJ | 100μJ@100kHz | |||
| Average Power Stab | - | 2.0% rms | |||
| Pulse-to-Pulse instabili | - | 3.0% rms | |||
| Spatial Mode | - | TEM00 (M2 <1.40) | |||
| Beam Roundnes | - | 90% | |||
| Beam Divergence | mrad | 2.0mrad (Full Angle) | |||
| Polarization Direction | Horizontal | ||||
| Polarization Ratio | 100:1 | ||||
| Electrical Parameter |
Operating voltage | V | 110 | - | 260 |
| Other parameters | Warm-up Time | mins | - | - | 20 |
| Operation Temperature | ℃ | 15 | - | 30 | |
| Storage Temperature | ℃ | -10 | - | 50 | |
| Cooling | sec | - | Water-cooling | 10 | |
| Relative Humidity | - | 15 | - | 80% | |
