Medical Use 10W Detachable Diode Laser 980nm wavelength
Price:
Negotiable
MOQ:
1 Piece/Pieces
Delivery Time:
4-8weeks
Brand:
BWT
Product Description
Features:
980nm wavelength
10W output power
200μm fiber core diameter
0.22 NA
Additional Functions:
Aiming beam
Fiber & Power monitor
Thermistor
Applications:
Medical use
|
Specifications(25℃)
|
Symbol
|
Unit
|
K980F14CC-10.00W | |||
| Minimum | Typical | Maximum | ||||
| Optical Data | CW-Output Power | Po | W | 10 | - | - |
| Center Wavelength | λc | nm | 980±10 | |||
| Wavelength Shift with Temperature | △λ/△T | nm/℃ | - | 0.3 | - | |
| Electrical Data | Electrical-to-Optical Efficiency | PE | % | 48 | - | |
| Threshold current | lth | A | - | 1.0 | - | |
| Operating current | lop | A | - | - | 12.5 | |
| Operating voltage | Vop | V | - | - | 2.0 | |
| Slope Efficiency | η | W/A | - | 0.9 | - | |
|
Fiber Data
|
Core diameter | Dcore | μm | - | 200 | - |
| Numeric aperture | NA | NA | - | 0.22 | - | |
| Fiber xConnector | - | - | - | SMA905 | - | |
| Thermistor | Rt | (K Ω)/(25℃) | 10±3% | |||
| PD | PD | µA | 100 2000 | |||
| TEC | Max. Current | Itec | A | 6 | ||
| Max. Voltage | Vtec | V | 9.8 | |||
| Others | ESD | Vesd | V | - | - | 500 |
| Storage temperature | Tst | ℃ | -20 | - | 70 | |
| Lead Soldering Temp | Tls | ℃ | - | - | 260 | |
| Lead Soldering Time | t | sec | - | - | 10 | |
| Operating case temperature | Top | ℃ | 15 | - | 30 | |
| Relative Humidity | RH | % | 15 | - | 75 | |
| Aiming Beam | Output Power | Pa | mW | 2 | - | |
| Wavelength | la | nm | 635±10 | |||
| Voltage | Va | V | 5V(Constant) | |||
