Industrial Grade Ultrafast Laser 75W Infrared Picosecond Laser
The 75W infrared picosecond laser is an industrial-grade ultrafast laser that uses a fiber seed source combined with solid-state amplification technology. It adopts an all-in-one machine design, the main body is completely sealed in a closed cavity, and there are multiple sensor monitors inside, which ensures the stability and reliability of the laser, and is suitable for 7 X 24 hours of industrial precision machining applications.
Features:
Power:﹥75W@100kHz at burst counts 4
Max Energy:＞750μJ@100kHz at burst counts 4 2mJ customized
Pulse Width:<15ps High Beam Quality
Compact Design
Stable output power and pulse energy
Applications:
Glass, Ceramic, Sapphire etc cutting and hole drilling
Precision Laser Marking
Metallic parts precision processin
| Parameters | Unit | Topaz 1064-7 | |||
| Minimum | Typical | Maximum | |||
| Optical Data | Power | W | 75 | - | - |
| Wavelength | nm | 1064 | |||
| Repetition frequency | khz | 5 | - | 1000 | |
| Pulse Width | ps | - | - | 15 | |
| Average Power | w | 75W@100kHz at burst count 4 | |||
| Maximum Pulse Energy | mJ | 750μJ@100kHz at burst count 4 | 2mJ@20kHz at burst count 4 customized- | ||
| Average Power Stab | - | 2.0% rms | |||
| Pulse-to-Pulse instabili | - | 3.0% rms | |||
| Spatial Mode | - | TEM00 (M2 <1.40) | |||
| Beam Roundnes | - | 85% | |||
| Beam Divergence | mrad | 2.0mrad (Full Angle) | |||
| Polarization Direction | Horizontal | ||||
| Polarization Ratio | 100:1 | ||||
| Electrical Parameter |
Operating voltage | V | 110 | - | 260 |
| Other parameters | Warm-up Time | mins | - | - | 20 |
| Operation Temperature | ℃ | 15 | - | 30 | |
| Storage Temperature | ℃ | -10 | - | 50 | |
| Cooling | sec | - | Water-cooling | 10 | |
| Relative Humidity | - | 10% | - | 80% | |
