30W Picosecond IR Laser 1064nm Wavelength 300uJ@100kHz
The new generation 30W picosecond infrared laser is a cost-effective industrial-grade picosecond laser. This product optimizes the optical path design, makes the volume more compact, and has significantly improved stability and reliability.
Features:
Power:＞30W@100kHz at burst counts 4 ＞25W@50kHz at burst counts 4
Max Energy:＞300μJ@100kHz at burst counts 4 ＞500μJ@50kHz at burst counts 4
High Beam Quality
Compact Design
Stable output power and pulse energy
Applications:
Thin glass, Ceramic, Sapphire etc cutting and hole drilling
Sapphire wafer Stealth laser dicing
Precision Laser Marking
Laser ablation of electrodes layer for Li-ion battery
Metallic parts precision processin
| Parameters | Unit | Topaz 1064-30New | |||
| Minimum | Typical | Maximum | |||
| Optical Data | Power | W | 30 | - | - |
| Wavelength | nm | 1064 | |||
| Repetition frequency | khz | 10 | - | 1000 | |
| Pulse Width | ps | - | - | 15 | |
| Average Power | w | 30W@100kHz at burst count 4 | |||
| Maximum Pulse Energy | mJ | 300μJ@100kHz at burst count 4 | - | ||
| Average Power Stab | - | 2.0% rms | |||
| Pulse-to-Pulse instabili | - | 3.0% rms | |||
| Spatial Mode | - | TEM00 (M2 <1.40) | |||
| Beam Roundnes | - | 90% | |||
| Beam Divergence | mrad | 2.0mrad (Full Angle) | |||
| Polarization Direction | Horizontal | ||||
| Polarization Ratio | 100:1 | ||||
| Electrical Parameter |
Operating voltage | V | 110 | - | 260 |
| Other parameters | Warm-up Time | mins | - | - | 20 |
| Operation Temperature | ℃ | 15 | - | 30 | |
| Storage Temperature | ℃ | -10 | - | 50 | |
| Cooling | sec | - | Water-cooling | 10 | |
| Relative Humidity | - | 10% | - | 80% | |
