High Power and Narrow Pulse Width IR Femtosecond Laser
The high-power narrow-pulse-width femtosecond laser adopts an all-fiber structure and an integrated sealed cavity, with stable performance and strong anti-interference ability. Pulse widths less than 200 fs and high temporal quality are achieved with efficient nonlinearity and dispersion management. The fiber femtosecond laser has good application value and prospects in bioimaging, optogenetics, ultrafast spectroscopy and other fields, and is also very popular in the processing of some organic thin film materials, especially flexible electronic materials.
Features:
Dimension : L461.5 x W352.7 x H169.6 (mm)
Power:>10W@50MHz
Max Energy:>200nJ@50MHz
Pulse width:200fs-1.5ps
Beam Quality:TEM00(M²<1.4)
Beam Roundness:>90%
Low-cost; maintenance-free
Narrow pulse width; Excellent pulse quality and stability
High beam quality; Suitable for precision processing
Real-time state monitoring
User-friendly interface
Applications:
biological imaging
Photogenetic research
chemical reaction kinetics
ultrafast spectroscopy
Micro-nano processing
Precision marking
Other precision processing and scientific research
| Parameters | Unit | BFL-1030-10LE | |
| Specifications | |||
| Optical Data | Power | W | 10 |
| Wavelength | nm | 1030 | |
| Pulse Repetition Rate | khz | 500M | |
| Pulse Width | ps | 200 | |
| Average Power | w | 10 | |
| Maximum Pulse Energy | mJ | 200 | |
| Average Power Stability | - | 2.0% rms | |
| Pulse-to-Pulse Instability | - | 3.0% rms | |
| Spatial Mode | - | TEM00 (M2 <1.40) | |
| Beam Roundnes | - | 90% | |
| Beam Divergence | mrad | 2.0mrad (Full Angle) | |
| Polarization Direction | vertical | ||
| Polarization Ratio | 100:1 | ||
| Electrical | Operating voltage | V | 220 |
| Parameter | |||
| Other parameters | Warm-up Time | mins | 10 |
| Ambient Temperature | ℃ | 15-30 | |
| Storage Temperature | ℃ | -10-80 | |
| Cooling Approach | sec | Air-cooling | |
| Relative Humidity | - | 10%-80% | |
