Fiber Coupled 150 Watt Blue Laser Diode 445nm For Material Processing
Price:
Negotiable
MOQ:
1 Piece/Pieces
Delivery Time:
4-8weeks
Brand:
BWT
Product Description
The wavelength of the blue diode laser is 445nm, the power range is from 800mW to 1000W, and a variety of fiber cores are available (105um~400um). Because of its high photon energy advantage, it has the characteristics of high absorption rate and no spatter in the processing of metal materials such as copper. It has irreplaceable advantages in the field of 3C electronics and lithium battery welding.
Features:
450nm wavelength
150W output power
105µm fiber core diameter
0.22NA
Cooling mode: water cooling
Applications:
Material processing
3D printing
|
Specifications(25℃)
|
Symbol
|
Unit
|
K445HR6FN-150.0WN1N-10522
|
|||
| Minimum | Typical | Maximum | ||||
| Optical Data | CW-Output Power | Po | W | 150 | - | - |
| Center Wavelength | λc | nm | 445±20 | |||
|
Number of submodules
|
pcs |
3
|
||||
| Spectral Width (FWHM) | △λ | nm | - | 6 | - | |
| Wavelength Shift with Temperature | △λ/△T | nm/℃ | - | 0.1 | - | |
| Wavelength Shift with Current | △λ/△A | nm/A | - | 1 | - | |
| Electrical Data | Electrical-to-Optical Efficiency | PE | % | 30 | - | |
|
Power Supply Mode
|
- | - | - |
3 modules
|
||
| Threshold current | lth | A | - | 0.5 | - | |
| Operating current | lop | A | - | 3 | 3.5 | |
| Operating voltage | Vop | V | - | 52 | 60 | |
| Slope Efficiency | η | W/A | - | 18.5 | - | |
|
Fiber Data
|
Core diameter | Dcore | μm | - | 105 | - |
| Numeric aperture | NA | NA | - | 0.22 | - | |
| Fiber length | Lf | m | - | 5.5 | - | |
| Minimum Bending Radius | - | mm | 50 | - | - | |
| Fiber termination | - | - | - |
HP-SMA905
|
- | |
| Thermistor | Rt | (KΩ)/β(25℃) | - | 10±3%/3450 | - | |
| Others | ESD | Vesd | V | - | - | 500 |
| Storage temperature | Tst | ℃ | -20 | - | 70 | |
| Lead Soldering Temp | Tls | ℃ | - | - | 260 | |
| Lead Soldering Time | t | sec | - | - | 10 | |
| Operating case temperature | Top | ℃ | 15 | - | 35 | |
| Relative Humidity | RH | % | 15 | - | 75 | |
(1)Data measured under operation output at 200W@20℃.
(2)A non-condensing environment is required for operation and storage.
(3)Operating temperature defined by the thermistor. Acceptable operating range is 15℃~30℃,but performance may vary.
(4)Product delivery qualification standards: Ibeginning of life ≤ 3.5A,Pbeginning of life ≥ 200W;
(5)Within the warranty period, the product is considered qualified with Iend of life =3.5A,Pend of life≤160W.
