HLY Rechargeable Cylindrical 2200mah 18650 Battery For Electric Bikes
Overview
Product Description
| 1. Long cycle life and high energy density | |||||||
| 2. Safety performance design | |||||||
| 3. Consistency assurance | |||||||
| 4. Energy system full equalization | |||||||
| 5. High safety, meeting international safety standards | |||||||
| 6. Independent development and design | |||||||
| 7. Multiple protections ensure safe use and extend span life | |||||||
| 8. A variety of cell types for choice, suitable for many different product fields. | |||||||
| 9. Widely operating temperature range, stable under high and low temperature. | |||||||
| 10. No fire,No explosion,No leakage |
Product description:
Paramenters:
| Normal capacity | 2200 mAh/0.5C |
| Minimum capacity | 2200 mAh/0.5C |
| Normal voltage | 3.7V |
| Charging voltage | 4.2 ±0.05 V |
| Discharge ending voltage | 2.75±0.05 V |
| Standard charging current | 0.5C(1100 mA) |
| Standard discharge current | 0.5C(1100 mA) |
| Max charge current | 1C(T≥10℃) 0.2C(10℃>T≥0℃) |
| Max discharge current | 2C(T≥0℃) 1C(0℃>T≥-10℃) 0.5C(-10℃>T≥-20℃) |
| Max recommended charge and discharge cell body temperature |
Charge:0~ 60℃ Discharge:-20~ 60℃ |
| Maximum short term allowable charge and discharge cell body temperature. Charging and discharging at these conditions will shorten cell cycle life. |
Charge: 75℃ Discharge: 75℃ |
| Humidity range | 0~90%RH |
| Internal resistance | ≤60 mΩ(AC Impedance, 1000 Hz) |
| Cell dimension | Height : 65.1 mm Diameter :18.4mm |
| Charging Time | About 150minutes at 0.5C |
Application:
Test Instruments:
FAQ:
Q1. Can I have a sample order for Battery?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 1-2 days, neutral order mass production time needs 3-7 working days. If OEM orders, would be about 30 days.
Q3. Do you have MOQ for Your Batteries?
A: OEM orders MOQ is 20000pcs. We can also accept small quantity for neutral orders.
Q4. How do you ship the goods and how long does it take to arrive?
A: DHL, UPS, FedEx or TNT for samples. Shipping time depends on the way you choose. Airline and sea shipping also optional.
Q5. Is it OK to print my logo on the product?
A: Yes. We welcome OEM and ODM orders.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
