Practical Multipurpose 2.5 mm Thermal Pad , 2W/m.K Silicone Pad For Laptop
China 2.0W/m.K 0.5mm 1mm 2mm 2.5mm ultra soft thermal pad for laptop cooling
| Attribute | Value | Test Method |
|---|---|---|
| Composition | Ceramic Filler, Silicone, and Reinforced Fiberglass | - |
| Color | White and Brick Red | Visual |
| Thickness(mm) | 0.5~12.0 | ASTM D374 |
| Density(g/cc) | 2.5 | ASTM D792 |
| Hardness(shore oo) | 30±5 | ASTM D2240 |
| Tensile Strength(KN/m) | 2.5 | ASTM D624 |
| Elongation(%) | 60 | ASTM D412 |
| Usage Temperature(℃) | -40~150 | -- |
| Electrical | ||
| Breakdown Voltage(kv/mm) | ≥7.0 | ASTM D149 |
| Dielectric Constant(@10mhz) | 5.7 | ASTM D150 |
| Volume Resistivity(Ω.cm) | 1.0*1013 | ASTM D257 |
| Flammability | V-0 | UL94 |
| Thermal | ||
| Thermal conductivity(W/m.K) | 1.0±0.1 | ASTM D5470 |
Product feature:
■ Thermal Conductivity:1.0 W/m.K
■ the material is soft, good compression performance, good thermal insulation performance, adjustable thickness range is relatively large, suitable for filling the cavity, both sides have natural viscosity, operability and maintainability;
■ with the addition of thermal silica gel, can make the contact surface between the heat source and the radiator better full contact, really do face to face contact. The reaction at temperature can achieve as small a temperature difference as possible;
■ High cut through resistance
■ High breakdown voltage
■ High Tear Strength 2.5 kN /m
■ Elongation 60%
Typical applications:
■ Networking and Telecommunications
■ IT: Notebooks, Tablets, Power Conversion
■ IT: Automotive: Control Modules, Turbo Actuators
■ Consumer Electronics: Gaming Systems, and LCDs
Purchase information:
Standard size: 200*400mm, which can be die-cut into various sizes and shapes as specified by customers. The increasing gradient of thickness is 0.25mm
