White Heatproof Thermal Conductive Encapsulant ,Silicone Potting Compound
Thermally Conductive Encapsulant Transparent Silicone Encapsulant For Solar Cells
| Attribute | Value | Test Method |
|---|---|---|
| Composition | Ceramic filler + Silicone | - |
| Color/Component A | White | Visual |
| Color/Component B | Sliver Grey | Visual |
| Density(g/cc) | 1.8 | ASTM D792 |
| Usage Temperature(℃) | -40~150 | -- |
| Electrical | ||
| Breakdown Voltage(kv/mm) | ≥10.0 | ASTM D149 |
| Dielectric Constant(@10mhz) | 5.5 | ASTM D150 |
| Volume Resistivity(Ω.cm) | 1.0*1015 | ASTM D257 |
| Flammability | V-0 | UL94 |
| Thermal | ||
| Thermal conductivity(W/m.K) | 0.8 | ASTM D5470 |
| Viscosity/Component A (cps) | 4500 | ASTM D2196 |
| Viscosity/Component B (cps) | 4500 | ASTM D2196 |
| Hradness,after cure(shore OO) | 60 | ASTM D22240 |
| Working Time@25℃(min) | 30 | ISO 9048 |
Product feature
■ Thermal conductivity: 1.0~2.0 W/m.K
■ Electrically insulating
■ High conformability
■ Pls put part A and part B in separate container and stir evenly before mixing the two part together.
Typical applications
■ Industrial: LEDs, Power Supplies
■ Automotive: OBC, DC/DC Converter, Amplifiers
■ Consumer Electronics: DC Converters, High Voltage Applications
Purchasing Information
Packing specification: 50 ml (25 ml each part)/ 400 ml (200 ml each part)/20 kg(10 kg each part)
Directions for use
• Working time @ 25C: 30-120 min
• For best results, ensure a 1:1 mix ratio is maintained
• Full cure @ 25C: 4 hours
• Full cure @ 100C: 5 minutes
Storage
Store in a cool, dry, well-ventilated place.
Shelf life
Shelf life of the product is 12 months after date of shipment.
