1.2 W/m.K Ultra Soft Thermal Conductive Pad 10mm Thickness For Electronics
Price:
Negotiable
MOQ:
1000 pcs
Delivery Time:
13-15 working days
Brand:
AOK
Product Description
1.2 W/m.k Thermal Conductivity 10.0 mm Thickness Ultra Soft Thermal Conductive Pad
| Attribute | Value | Test Method |
|---|---|---|
| Composition | Ceramic Filler + Silicone | - |
| Color | Pink | Visual |
| Thickness (mm) | 0.5~12.0 | ASTM d374 |
| Density (g/cc) | 2.3 | ASTM D792 |
| Hardness (Shore OO) | 20±5 | ASTM D2240 |
| Tensile Strength(kn/m) | 0.4 | ASTM D624 |
| Elongation % | 52 | ASTM D412 |
| Usage Temperature(℃) | -40~150 | - |
| Electrical | ||
| Breakdown Voltage(kv/mm) | ≥6.5 | ASTM D149 |
| Dielectric Constant(@1mhz) | 5.3 | ASTM D150 |
| Volume Resistivity(Ω.cm) | 1.0*1012 | ASTM D257 |
| Flammability | V-0 | UL94 |
| Thermal | ||
| Thermal conductivity(W/m.K) | 1.2±0.1 | ASTM D5470 |
Product feature:
- Thermal Conductivity:1.2 W/m.K
- Ultra soft and highly compliant
- Naturally tacky, easing application
- Low pressure versus deflection
- Excellent, high volume applications
Typical applications:
- Networking and Telecommunications
- IT: Notebooks, Tablets, Power Conversion
- Industrial: LEDs, Power Supplies and Conversion
- Automotive: Control Modules, Turbo Actuators
- Consumer Electronics: Gaming Systems, and LCDs
