2 W/m.K Grey Thermal Conductive Pad For Electronics Heat Transfer
Price:
Negotiable
MOQ:
1000 pcs
Delivery Time:
13-15 working days
Brand:
AOK
Product Description
| Attribute | Value | Test Method |
|---|---|---|
| Composition | Ceramic Filler + Silicone | - |
| Color | Grey | Visual |
| Thickness(mm) | 0.5~10.0 | astm d374 |
| Density(g/cc) | 2.8 | ASTM D792 |
| Hardness(shore oo) | 25 | ASTM D2240 |
| Elongation(%) | ＞100 | ASTM D412 |
| Usage Temperature(℃) | -40~150 | -- |
| Electrical | ||
| Breakdown Voltage(Kv/mm) | 6.0 | ASTM D149 |
| Dielectric Constant(@10Mhz) | 7.0 | ASTM D150 |
| Volume Resistivity(Ω.cm) | 1013 | ASTM D257 |
| Flammability | V-0 | UL94 |
| Thermal | ||
| Thermal conductivity(W/m.K) | 2.0 | ASTM D5470 |
Product feature:
-
Soft and flexible, low hardness, wide range of thickness, can fill any uneven size gap
-
Meet ROHS,UL and SGS environmental requirements.
-
Naturally tacky, easing application
-
Low pressure versus deflection
-
Low viscosity on both sides, easy to install and reusable
Typical applications:
-
Networking and Telecommunications
-
IT: Notebooks, Tablets, Power Conversion
-
Industrial: LEDs, Power Supplies and Conversion
-
Automotive: Control Modules, Turbo Actuators
-
Consumer Electronics: Gaming Systems, and LCDs
