Silicone Ultrasoft Heat Conductive Pad , Solid Thermal Pad High Conductivity
Price:
Negotiable
MOQ:
1000pcs
Delivery Time:
13-15working days
Brand:
AOK
Product Description
Thermal Conductive Pad with 1.5W/m.K High cut through resistance Low volatility gap filler
| Attribute | Value | Test Method |
|---|---|---|
| Composition | Ceramic Filler + Silicone | - |
| Color | Light Grey | Visual |
| Thickness(mm) | 1.0~10.0 | ASTM d374 |
| Density(g/cc) | 2.5 | ASTM D792 |
| Hardness(shore oo) | 40±5 | ASTM D2240 |
| Usage Temperature(℃) | -40~150 | -- |
| Electrical | ||
| Breakdown Voltage(Kv/mm) | ≥7.0 | ASTM D149 |
| Dielectric Constant(@1MHz) | 6.66 | ASTM D150 |
| Volume Resistivity(Ω.cm) | 1013 | ASTM D257 |
| Flammability | V-0 | UL94 |
| Thermal | ||
| Thermal conductivity(W/m.K) | 1.5±0.1 | ASTM D5470 |
Product feature
■ Solid, soft and flexible, have high and low viscosity type
■ Good insulation, withstanding high voltage and temperature
■ Naturally tacky, easing application
■ Low pressure versus deflection
■ Excellent, high volume applications
Typical applications
■ Networking and Telecommunications
■ IT: Notebooks, Tablets, Power Conversion
■ Industrial: LEDs, Power Supplies and Conversion
■ Automotive: Control Modules, Turbo Actuators
■ Consumer Electronics: Gaming Systems, and LCDs
