Green Rubber Heat Thermal Conductive Pad Heatproof Weather Resistant
Green thermal rubber pad Thermal Conductive Pad With 5.0W/m.K For Power Supplies thermal gap filler
|
Attribute |
Value |
Test Method |
|---|---|---|
|
Composition |
Ceramic Filler + Silicone |
- |
|
Color |
Dark green |
Visual |
|
Thickness(mm) |
1.0~6.0 |
ASTM D374 |
|
Density(g/cc) |
3.2±0.1 |
ASTM D792 |
|
Hardness(shore oo) |
50±5 |
ASTM D2240 |
|
Usage Temperature(℃) |
-40~200 |
-- |
|
Electrical |
|
|
|
Breakdown Voltage(kv/mm) |
≥6.0 |
ASTM D149 |
|
Dielectric Constant(@10mhz) |
7.4 |
ASTM D150 |
|
Volume Resistivity(Ω.cm) |
1010 |
ASTM D257 |
|
Flammability |
V-0 |
UL94 |
|
Thermal |
|
|
|
Thermal conductivity(W/m.K) |
5.0±0.3 |
ASTM D5470 |
Product feature
■ Thermal conductivity: 5.0 W/m.k
■ Naturally tacky, easing application
■ The thermal conductivity of the thermal silica gel sheet is adjustable and the thermal stability is better;
■ Excellent, high volume applications
■ Elevated Temperature Resistance
Typical applications
■ Networking and Telecommunications
■ Industrial: LEDs, Power Supplies and Conversion
■ Automotive: Control Modules, Turbo Actuators
■Consumer Electronics: Gaming Systems, LCDs, and Graphic Cards
Purchase information:
Standard size: T≤1.5mm,size=200*400mm; T＞1.5mm,size=150*150; which can be die-cut into various sizes and shapes as specified by customers. The increasing gradient of thickness is 0.25mm.
