Industrial Water Tube Oil Gas Fired Steam Boiler Double Drums D Type Industrial Steam Boilers
EPCB Industrial Water Tube Oil Gas Fired Steam Boiler
Capacity: 4~35T/h
Pressure: 1.25~2.5MPa
Fuel: Diesel, Natural Gas, Heavy Oil, LPG, CNG, Fuel Oil, Biogas, City Gas, Methane Gas, etc.
Application: Pharmaceutical Factories, Breweries, Chemical Factories, Garment Factories, Canneries, Oil Mills, Textile Mills, Printing and Dyeing Factories, Fruit Juice Factories, Candy Factories, Fish Meal Factories, Feed Factories, Slaughterhouses...
Find the capacity of the oil/gas fired steam boiler you want and check other parameters of the boiler as a reference.
| ItemModel | Automatic Horizontal Water Tube Oil Gas Fired Steam Boiler | |||||||||
| Rated steam capacity (Ton/h) | 4 | 6 | 8 | 10 | 15 | 20 | 25 | 30 | 35 | |
| Rated steam pressure MPa | 1.25/1.6/2.5 | |||||||||
| Rated steam temperature ℃ | 194/203/225/400 | |||||||||
| Design efficiency % | 92.26 | 92.23 | 92.22 | 92.26 | 92.26 | 91.99 | 91.82 | 91.99 | 92.17 | |
| Feed water temperature ℃ | 20 | 105 | 105 | 105 | 105 | 105 | 105 | 105 | 105 | |
| Available fuel | Diesel, heavy oil, natural gas, LPG, city gas, fuel oil, CNG, etc | |||||||||
| Fuel consumption | Diesel kg/h | 267.45 | 402.68 | 535.2 | 668.6 | 1002.6 | 1337.3 | 1671.6 | 2005.9 | 2336.8 |
| Natural gas Nm3/h | 329.4 | 425.9 | 567.9 | 709.6 | 1064.3 | 1418.4 | 1773.1 | 2127.6 | 2477.4 | |
| Overall dimension | Length m | 5.2 | 5.9 | 7.2 | 7.8 | 8.5 | 9.2 | 11.4 | 11 | 11.2 |
| Width m | 2.7 | 2.7 | 3.4 | 3.4 | 3.6 | 3.7 | 3.7 | 3.9 | 4.6 | |
| Height m | 3.2 | 3.2 | 3.5 | 3.6 | 3.6 | 3.7 | 3.8 | 4.6 | 5.2 | |
-
The series of boilers are double drums D-type water tube boilers. The furnace is formed by covering membrane water wall, which effectively increases the heating surface, makes the water in the boiler fully contact with the flue gas, heat up fast with high thermal efficiency.
-
Equipped with Italian/German/Finnish well-known brand burners, such as Italy's Rello, Baltur; Germany's Weishaupt; Finland's Oilon, etc., make fuel burn more fully, and the emission indicators of pollutants are far below the national emission standards. Nitrogen oxide emissions can be as low as 30 mg/Nm3.
-
Equipped with spiral finned tube type high-efficiency economizer, effectively recovering heat energy in flue gas and heating boiler feed water. It can save more fuel costs for users and improve the boiler thermal efficiency!
-
According to the capacity of the boiler, this series of boilers adopt assembly and semi-assembly structure, which can shorten the installation period effectively, and have compact structure, small installation volume so that they can save users’ investment.
-
Boiler body adopts double-layer aluminium silicate material with good thermal insulation performance. The exterior of the boilers adopts concave and convex pressing guard plate, which has beautiful appearance and good air tightness.
![]()
Our Services:
1. 100%safety, running stably, excellent water level and pressure control, fully automatic operation.
2. Boiler running life > 20years.
3. Good after-sale service. It is free for you to get the damaged spares in warranty period (1 year) if there is any questions. Assure that we can supply you spares in boiler’s all life.
4. We can arrange engineer to your company for installation and commissioning and training. If you need us at any time, we can send our technicians and prepare in a short time.
5. Special paint is used after assembly. Paint is particularly used in your climate area, which is anti-corrosion, anti-abrasion and color-fastness.
