High Torque Gerotor Hydraulic Motor BMP BMPH BMPW 80 100 160 315 400 500
1.Name:BMP/BMPH/BMPW Series Hydraulic Motor
2.Introduce:
BMP/BMPH/BMPW series motor are small volume, economical type, which is designed with shaft distribution flow,which adapt the Gerotor gear set design and provide compact volume, high power and low weight.
3.Characteristic features:
(1) Advanced manufacturing devices for the Gerotor gear set, which provide small volume. high efficiency and long life.
(2)Shaft seal can bear high pressure of motor of which can be used in parallel or in series.
(3)Advanced construction design, high power and low weight.
4.Main Specification:
(1)Technical data for BMP with 25 and 1 in and 1 in splined and 28.56 tapered shaft
| Type | BMP BMPH BMPW 36 |
BMP BMPH BMPW 50 |
BMP BMPH BMPW 80 |
BMP BMPH BMPW 100 |
BMP BMPH BMPW 125 |
BMP BMPH BMPW 160 |
BMP BMPH BMPW 200 |
BMP BMPH BMPW 250 |
BMP BMPH BMPW 315 |
BMP BMPH BMPW 400 |
BMP BMPH BMPW 500 |
|
| Geometric displacement (cm-rev.) | 36 | 51.7 | 77.7 | 96.2 | 120,2 | 157.2 | 194.5 | 240.3 | 314.5 | 389.5 | 486.5 | |
| Max.speed(rpm) | cont. | 1500 | 1150 | 770 | 615 | 490 | 383 | 310 | 250 | 192 | 155 | 120 |
| int. | 1650 | 1450 | 960 | 770 | 615 | 475 | 385 | 310 | 240 | 190 | 150 | |
| Max.torque(Nm) | cont. | 55 | 100 | 146 | 182 | 236 | 302 | 360 | 380 | 375 | 360 | 385 |
| int. | 76 | 128 | 186 | 227 | 290 | 370 | 440 | 460 | 555 | 525 | 560 | |
| peak | 96 | 148 | 218 | 264 | 36D | 434 | 540 | 550 | 650 | 680 | 680 | |
| Max. output(kw) | cont. | 8.0 | 10.0 | 10.0 | 11.0 | 10.0 | 10.0 | 10.0 | 8.5 | 7.0 | 6.0 | 5.0 |
| int. | 11.5 | 12.0 | 12.0 | 13.0 | 12.0 | 12.0 | 12.0 | 10.5 | 8.5 | 7.0 | 6.0 | |
| Max.pressure drop (MPa) |
cont. | 12.5 | 14 | 14 | 14 | 14 | 14 | 14 | 11 | g | 7 | 6 |
| int. | 16.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 14 | 14 | 10.5 | g | |
| peak | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 18 | 16 | 14 | 12 | |
| Max. flow(Lmin) | cont. | 55 | 6O | 6o | 60 | 60 | 6D | 6o | 6o | 6o | 6o | 6o |
| int. | 60 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | |
| Weight(kg) | 5.6 | 5.6 | 5.7 | 5.9 | 6.0 | 6.2 | 6.4 | 6.7 | 6.9 | 7.4 | 8 | |
*Continuous pressure:Max. value of operating motor continuously.
*Intermittent pressure:Max. value of operating motor in 6 seconds per minute.
*Peak pressure:Max. value of operating motor in 0.6 second per minute.
(2)Technical data for BMP with 31.75 and 32 shaft
| Type | BMP BMPH 36 |
BMP BMPH 5o |
BMP BMPH 8o |
BMP BMPH 10o |
BMP BMPH 125 |
BMP BMPH 160 |
BMP BMPH 200 |
BMP BMPH 250 |
BMP BMPH 315 |
BMP BMPH 400 |
BMP BMPH 5oo |
|
| Geometric displacement (cm'rev.) | 36 | 51.7 | 77.7 | 96.2 | 120.2 | 157.2 | 194.5 | 240.3 | 314.5 | 389.5 | 486.5 | |
| Max.speed(rpm) | cont. | 1500 | 1150 | 770 | 615 | 490 | 383 | 310 | 250 | 192 | 155 | 120 |
| int. | 1650 | 1450 | 960 | 770 | 615 | 475 | 385 | 310 | 240 | 190 | 150 | |
| Max. torque(Nm) | cont. | 55 | 100 | 146 | 182 | 236 | 302 | 360 | 460 | 475 | 490 | 430 |
| int. | 76 | 128 | 186 | 227 | 290 | 370 | 440 | 570 | 555 | 580 | 560 | |
| peak | 96 | 148 | 218 | 264 | 360 | 434 | 540 | 670 | 840 | 840 | 780 | |
| Max. output(kW) | cont. | 8.0 | 10.0 | 10.0 | 11.0 | 10.0 | 10.0 | 10.0 | 8.5 | 7.0 | 6.0 | 6.0 |
| int. | 11.5 | 12.0 | 12.0 | 13.0 | 12.0 | 12.0 | 12.0 | 10.5 | 8.5 | 7.0 | 7.0 | |
| Max.pressure drop (MPa) |
cont. | 12.5 | 14 | 14 | 14 | 14 | 14 | 14 | 14 | 12 | 9.5 | 7 |
| int. | 16.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 14 | 11.5 | g | |
| peak | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 22.5 | 18 | 13 | |
| Max. flow(Lmin) | cont. | 55 | 6o | 6o | 60 | 6o | 60 | 60 | 60 | 60 | 60 | 60 |
| int. | 60 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | 75 | |
| Weight(kg) | 5.6 | 5.6 | 5.7 | 5.9 | 6.0 | 6.2 | 6.4 | 6.7 | 6.9 | 7.4 | 8.0 | |
*Continuous pressure:Max.value of operating motor continuously.
*Intermittent pressure:Max.value of operating motor in 6 seconds per minute.
*Peak pressure:Max.value of operating motor in 0.6 second per minute
