China Continuous Galvalume Line Process 600-1250mm for sale

Continuous Galvalume Line Process 600-1250mm

Name: Continuous Galvalume Line Process 600-1250mm
Brand: Beijing JJRS Technology Development Co., Ltd.

Price Negotiable

Price: USD$1,000,000~USD10,000,000

MOQ: 1

Delivery Time: 7-10 months

Brand: JJRS

Product Description

90,000TPY hot dip galvanizing/galvalume line 0.23~0.8mm*600~1250mm (metal ss)

Product Overview

90,000TPY continuous hot dip galvanizing line

This line is a continuous hot dip galvanizing & galvalume combined line for cold rolled strip with the function and main

equipments of degreasing, annealing, galvanizing (GI+GL), skin pass mill (optional), tension leveler, passivation/antifinger

print, electrostatic oiling (optional) and so on. It has the capacity of 90,000 tons per year; the raw material is cold rolled

hard strip SPCC; the spec is 600-1250mm×0.10-0.80mm. The designed processing speed is Max. 140mpm. Quality of the products accord

with the standard of JIS G 3302; Total length of the line is about 128m.

FEATURES AT A GLANCE

1. The line is designed to be able to process cold rolled strip with annual capacity of 90,000 tons (based on working time 7200

hours/year).

2. The spec is 600-1250mm×0.230-0.80mm. The designed processing speed is Max. 140mpm.

We provide two kinds of technologiesof hot dip galvanizing (galvalume) lines: "United States Steel Corp"and independently researched and developed “JJRS-Sendzimir” .

Name	Steel strip continuous process galvanizing line (metal ss)
Application	Building Material
Width	600mm-1350mm
Thickness	0.12mm-0.8mm
Capacity	250,000t/year
Zinc Coating	30-300g/m2
