200000t Year Hot DIP Galvanizing Line Continuous Aluminum Zinc Plating Unit

Continuous Hot-DIP 55% Aluminum Zinc Plating Unit/Line, Galvalume Line

Beijing JJRS Technology Development Co., Ltd. registered in national high tech park-Beijing Economic and Technological Development Zone, is high-tech enterprise specialized in the complete set of metallurgical equipments, intensive processing of steel strip and metal surface coating engineering project, with the integration of mechanism, optics, electric and hydraulic pressure.

Innovation is our Mission. It is key for providing our customers with a competitive advantage. Our innovative engineering team applies our technology to offer a tailor made solution to your individual requirements consistent with your preferences, production goals and budgets.

The competitive advantage of JJRS stems from being able to offer the world's best technology at competitive pricing, with the backup of full & ongoing specialist support. In short, we offer a world class supply solution that is second to none.

Brief Introduction of 0.16~1.5mm*1250mm Continuous Galvalume Line

The continuous galvalume line is used to produce high quality galvalume steel sheets, it can realize the recrystallization annealing of cold rolled steel strip and deposit an equal thickness coating on the surface.

Process Flow

Main equipments according to processflow in turn are as follows:

Manually loading → entry skid → coil loading trolley I# & II# → pay off reel I# & II# → decoiling pinch rollI# & II# → transverse shearer I# & II# → join pinch roll → welder →riveter → roller leveler → tension bridle roll I# → entry accumulator → CPC double-roller centering machine I# → tension bridle roll II# → pre-degreasing →degreasing → washing I# → washing II# → purified water washing → hot air blowing device → chemical coating machine → chemical coating drying furnace →cold air blowing device → CPC double-roller centering machine II# → tension machine III# → base coating roller coater → base coating leveling chamber →base coating curing furnace → cold air blowing device → base coating forced cooling chamber → squeezing centering machine → hot air blowing device → tensionbridle roll IV# → CPC single roller centering machine I# → finishing coatingroller coater I# → finishing coating roller coater II# → leveling chamber → finishingcoating curing furnace → cold air blowing device → finishing coating forced cooling chamber → squeezing centering machine → hot air blowing device → tensionbridle roll V# → CPC double-roller centering machine III# → three color printing unit →printing thermal curing systemtensionbridle roll VI# → finishing roller coater → finishingleveling chamber → finishing curing furnace → hot laminating machine →finishing forced cooling chamber → squeezing centering machine → hot airblowing device → tension bridle roll VII# → cold laminating machine → exit accumulator→ CPC double-roller centering machine IV# → tension bridle roll VIII# → pinch shearer → exit pinch roll I# & II# → recoiler I# & II# (EPC) → coilunloading trolley I# & II# → auxiliary recoiler I# & II# → exit skid →manually unloading
