Double Impeller Agricultural Irrigation Gasoline Water Pump 3600rpm
Double impeller high pressure 3600rpm agricultural irrigation gasoline water pump single cylinder four stroke 32kg
Single impeller high pressure pump
THE BENEFIT:
1. our products are reliable in quality, stable in performance and durable to meet all your needs.
2. if there is any problem, we provide one year warranty service so that you have no worry after sale
3. surge power, enough horsepower, strong power, fuel saving, power saving, stable performance.
4. fully intelligent protection system, double protection of oil shortage and overload, absolute protection for your safety, will not put you in danger.
ADD: if you want to know more details, please contact us.
APPLICATION:It is used in farmland irrigation and drainage, as well as water supply and drainage in industrial and mining enterprises and cities and towns.
| The technical parameters of the water pump of Huanneng gasoline | Single impeller high pressure pump | Double impeller high pressure pump | |||||
| Brand model number | QGZ50-30 | QGZ80-30 | QGZ100-30 | QGZ150-20 | KN50HP-50 | KN50HP-80 | |
| engine | 170F | 170F | 190F | 190F | 170F | 170F | |
| 发动机 | Gasoline engine type | Single cylinder, four stroke, forced air valve, overhead valve | Single cylinder, four stroke, forced air valve, overhead valve | Single cylinder, four stroke, forced air valve, overhead valve | Single cylinder, four stroke, forced air valve, overhead valve | Single cylinder, four stroke, forced air valve, overhead valve | Single cylinder, four stroke, forced air valve, overhead valve |
| Maximum power output power | 7.5/3600hp/rpm | 7.5/3600hp/rpm | 15.0/3600hp/rpm | 15.0/3600hp/rpm | 7.5/3600hp/rpm | 7.5/3600hp/rpm | |
| Ignition system | Transistor Magnet Ignition | Transistor Magnet Ignition | Transistor Magnet Ignition | Transistor Magnet Ignition | Transistor Magnet Ignition | Transistor Magnet Ignition | |
| Bore diameter × stroke (mm) | 70×69mm | 70×69mm | 88×69mm | 88×69mm | 70×69mm | 70×69mm | |
| Displacement (mL) | 215cm3 | 215cm3 | 420cm3 | 420cm3 | 215cm3 | 215cm3 | |
| Oil volume L | 0.6 | 0.6 | 1.1 | 1.1 | 0.6 | 0.6 | |
| Rack (square pipe, round pipe, pipe diameter) | The rack can be made of diameter 25/28/32 series | The rack can be made of diameter 25/28/32 series | The rack can be made of diameter 25/28/32 series | The rack can be made of diameter 25/28/32 series | The rack can be made of diameter 25/28/32 series | The rack can be made of diameter 25/28/32 series | |
| impeller | cast iron | cast iron | cast iron | cast iron | cast iron | cast iron | |
| bearing | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | Stainless steel | |
| Pump housing material | cast iron | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | |
| 水泵 | Starting method | Manual start/electric start | Manual start/electric start | Manual start/electric start | Manual start/electric start | Manual start/electric start | Manual start/electric start |
| Power factor (cosφ) | 1 | 1 | 1 | 1 | 1 | 1 | |
| Insulation class | F | F | F | F | F | F | |
| Fuel tank volume L | 6L | 6L | 6L | 6L | 6L | 6L | |
| Inlet and outlet diameter | 50mm | 80mm | 100mm | 150mm | 50mm | 50mm | |
| Max lift | 20M | 25M | 45M | 20M | 40M | 80M | |
| suction lift | 6M | 6M | 6M | 7M | 6M | 6M | |
| Maximum flow | 40 cubic | 55 cubic meters | 80 cubic | 150 cubic meters | 22 cubic | 25 cubic meters | |
| Shell material | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | |
| L×W×H (mm) | 490*400*410 | 490*400*410 | 570*430*500 | 690*510*550 | 490*400*410 | 490*400*410 | |
| Net weight (Kg) | 25KG | 30KG | 40KG | 55KG | 30KG | 32KG | |
