6000W Fiber CW Pulsed Laser Source Single Mode

Price Negotiable

Price: Can be negotiation

MOQ: 1

Delivery Time: Negotiable

Brand: DK

Product Description

Product introductions

CW Fiber Laser, based on module design, has excellent beam quality and high stability, which structure is compact and water-cooling. The laser can be adjusted continuously, and the beam is transmitted be fiber and QBH connector, which is ideal for laser cutting, laser welding, etc . The laser is very suitable for system intergration with robot or machine tool, and is widely used for laser cutting, welding, 3D printing, electronics, automobile parts, aerospace, etc.

Product features

♦Ultra high stability

♦High WPE

♦Outstanding processing capacity

♦Excellent Performance

Product specification

Optical Parameters		DK-YMM 6000	DK-YMM 8000
Operation Mode		CW/Modulation	CW/Modulation
Polarization State		Random	Random
Beam Quality	M2	<10@100µm	<10@100µm
	BPP(mm·mrad)	≤3.4@100µm	≤3.4@100µm
Output Power		6000W	8000W
Output Fiber Diameter		100µm(50,200µmCustomizable)	100µm(200µmCustomizable)
Max. Modulation Frequency		5kHz	5kHz
Rise/Fall Time		<20µs	<20µs
Power Range		10%~100%	10%~100%
Output Power Instability		≤1.5%	≤1.5%
Center Wavelength		1080±10nm	1080±10nm
3dB Spectral Width		<6nm	<6nm
Indicated Light Wavelength		635nm	635nm
Indicated Light Power		>0.3mW	>0.3mW
Electronic Control Parameters		DK-YMM 6000	DK-YMM 8000
Operating Voltage		380V	380V
Operating Frequency		50Hz	50Hz
Laser Power Consumption		<20kW	<25kW
Other Parameters		DK-YMM 6000	DK-YMM 8000
Output Fiber Length		20m(Customizable)	20m(Customizable)
Cooling		Water Cooling	Water Cooling
Dimensions		1100mm×710mm×1350mm	1100mm×710mm×1350mm
Weight		360kg	430kg
Operating Temperature		10℃~40℃	10℃~40℃
Storage Temperature		-15℃~60℃	-15℃~60℃
Relative Humidity		20%-80%	20%-80%
