Super Speed Plastic Film Slitting Machine for BOPP PET CPP BOPP Film

1. Function:

1). Have automatic constant tension unwind, multiple-stations taper tension control center + surface-reeling up, rewind and machine stopped tension keep function.

2). Slitting into suitable harness, length and neatly roll material.

3). Have automatic guiding function.

4). Have secondary rewinding function.

2. Main technical parameters:

1). Slitting material: 0.012-0.12mm BOPP, PET;0.02-0.12mm CPP, BOPP film;

2). Maximum machine speed: 400m/min; Normal slitting speed 350m/min, machine running smoothly and steady, non obvious vibration or noise. Machine running smoothly and steady, non obvious vibration or noise.

3). Maximum load-bearing of unwind: 1500 kg; Maximum diameter: 1000 mm;

4). Maximum rewind diameter of rewind: 800 mm;

5). Maximum effective width: 2300mm; Maximum slitting width 1200mm

6). Minimum slitting width:400mm; (exceed 1200mm, we suggest use air-shaft for rewind)

7). Adaptable client's dedicated 6 inches steel tube for unwind.

8). Rewind uniformity less than 1 mm, it can be used for 6 inches and 3 inches paper-core rewind.

9).  Machine total power: AC 380V 4 line about 40 KW;

10). Air-source pressure more than 5kg/cm²

11). External dimension: 6000mm ×4400mm ×2100mm (L x W x H);

12). Machine body weight: about 12 Tons;

Seaworthy wooden stock

Professional service pre-sales

Products solutions

Factory solutions

Technical solution

Professional sales service

Project Information tracking

Technical support

Survey feedback

Installation tracking

We are an integrated professional Plant for manufacturing, designing and marketing of Slitting, Rewinding,Laminating, Coating, and Casting Film machinery facilities.

Over the years, we always set a motto of "science and technology as the guide, customer-focused", Products occupied the market quickly, and obtained widespread highly praise ,trust from the new and old clients.

Currently, 8 series of products and more than 70 models machinery has been developed as below:

1. High-speed wide range, plastic film etc 1 st time Slitting Series;

2. High-speed paper, plastic etc 2nd Slitting Series;

3. Special Slitting machine, Inspection machine, Rewinder Machine Series;

4. Gold & Silver Card-Paper Coating, Lamination, Peeling, Transferring machine Series;

5. High-speed CPP, CPE wide-range Casting film machine unit (1-6M) Series; CPP, CPE

6. High Glossy picture coating machine Series;

7. Multi-layers coextrusion tandem type extruder laminating machine unit (PE, PP, EVA);

8. UV 3D three-dimensional laser Carving Coating Machine;

Please feel free to contact if anything we can do for you, its our pleasure to be on service of you!
