An excavator pile driving boom is a specialized attachment that can be added to an excavator to turn it into a pile driving machine. It consists of a long boom that is attached to the excavator's arm and a hydraulic hammer that is mounted on the end of the boom. The hammer is used to drive steel or concrete piles into the ground, which can be used to support structures such as buildings, bridges, or retaining walls.
The excavator pile driving boom is designed to be versatile and can be used in a variety of soil conditions, including hard rock, clay, and sand. It is also able to drive piles to a range of depths, depending on the length of the boom and the power of the hydraulic hammer.
Excavator piling arm is a kind of excavator lengthening arm for piling. The standard arm of a conventional excavator can only play 6 meters of pile. By changing the middle hole of the big arm to the lower part of the big arm, it can only barely play 9 meters of the pile. The pile driving arm is straight, and the bucket rod cylinder is changed to the lower part of the arm, so it can reach higher.
1. Q355B as default, Q690D optional.
2. Key Force-bearing Parts are Reinforced.
3. Welding is full and smooth.
4. Adopt national standard precision pipelines.
5. Boom bushing come with an alloy copper sleeve(with self-lubriing carbon powder inside).
6. Boom and sticks' angle can be opened to achive 160°
| Excavator(Ton) | Total Length(mm) | (A)Boom(mm) | (B)Arm(mm) | (C)Piling Height)(mm) | Counterweight(Ton) |
| 30-36T | 13800 | 10000 | 3800 | 15400 | 3T |
| 30-36T | 15000 | 10500 | 4500 | 17100 | 5T |
| 40-45T | 15800 | 11000 | 4800 | 17900 | 3T |
| 40-45T | 16800 | 11500 | 5300 | 18500 | 5T-6T |
| 45-50T | 19000 | 12500 | 6500 | 21000 | 6T-7T |
