High Pressure Rexroth Directional Valves 4WRPE 4WRPH 4WRPEH 4WRLE10 4WRLE16 4WRLE25 4WRLE32 4WRPE6E 4WRPE
Price:
NIGOTIATION
MOQ:
1
Delivery Time:
15 work days
Brand:
Rexroth
Product Description
4/3 servo solenoid valves with on-board electronics (OBE), positive overlap and position feedbac
Rexroth Directional Valves 4WRPE 4WRPH 4WRPEH 4WRLE10 4WRLE16 4WRLE25 4WRLE32 4WRPE6E 4WRPE
Directional valves type WE are solenoid operated directional spool valves. They control the start, stop, and direction of a flow. These directional valves basically consist of housing; one or two solenoids; control spool; and no, one, or two return springs. A full array of spools are possible with variations in voltage and electrical connection, all within the program. Flow and pressure rates from 4000 PSI to 5000 PSI and 21 GPM to 32 GPM cover a wide range of applications.
Features
– Directly operated NG6 and 10 valves with positive overlap, actuated on both sides and position-controlled, symbol E or W – Control solenoid with on-board electronics (OBE), deadband compensation and gain calibrated at the factory
– Electrical connection 6P+PE (standard), signal input: differential amplifier with interface A1 = ±10 V (F1 on request)
– For subplate attachment, mounting hole configuration NG6 to ISO 4401-03-02-0-94 and NG10 to ISO 4401-05-04-0-94
– Plug-in connectors to DIN 43563-AM6, see catalog section RE 08008 (order separately)
– Subplates as per catalog section RE 45053 and RE 45055 (order separately) Variants on request
– For standard applications, such as e.g. Valve electronics 11P+PE (plug-in connector
Size 6
* For subplate mounting:
Porting pattern according to ISO 4401-3, NFPA T3.5.1M R1,
and ANSI B93.7 D 03
* Wet-pin AC or DC solenoids
* Solenoids with detachable coil
* Electrical connection as individual or central connection
* Optional spool position monitoring
* Smooth switching characteristics
* For subplate mounting:
Porting pattern according to ISO 4401-3, NFPA T3.5.1M R1,
and ANSI B93.7 D 03
* Wet-pin AC or DC solenoids
* Solenoids with detachable coil
* Electrical connection as individual or central connection
* Optional spool position monitoring
* Smooth switching characteristics
- Direct solenoid actuated directional spool valve high performance version
- Wet pin DC or AC solenoids with removable coil
- Solenoid coil can be rotated through 90o
- It is not necessary to open the pressure tight chamber when changing the coil
- Electrical connections either as individual or central connections
- Hand override, optional
- Wet pin DC or AC solenoids with removable coil
- Solenoid coil can be rotated through 90o
- It is not necessary to open the pressure tight chamber when changing the coil
- Electrical connections either as individual or central connections
- Hand override, optional
| Place of Origin | CHINA |
| Brand Name | REXROTH |
| Warranty | 1 Year |
| Showroom Location | None |
| Weight | 15 |
| Power | ., Hydraulic |
| Valve type | other |
| Condition | New |
| Type | Valves |
| Is customized | yes |
| Standard or Nonstandard | Standard |
| Usage | Oil |
| Material | Cast Iron |
| Package | Carton |
| MOQ | 1 Piece |
4WRPE 6 E 08SJ–2X/G24K0/A1M 0 811 404 148
4WRPE 6 E 18SJ–2X/G24K0/A1M 0 811 404 140
4WRPE 6 E 32SJ–2X/G24K0/A1M 0 811 404 141
4WRPE 6 W 08SJ–2X/G24K0/A1M 0 811 404 145
4WRPE 6 W 18SJ–2X/G24K0/A1M 0 811 404 142
4WRPE 6 W 18SJ–2X/G24K0/F1M 0 811 404 146
4WRPE 6 W 32SJ–2X/G24K0/A1M 0 811 404 143
4WRPE 6 W 32SJ–2X/G24K0/F1M 0 811 404 147
4WRPE 6 E 08SJ–2X/G24K0/A1M 0 811 404 148
4WRPE 6 E 18SJ–2X/G24K0/A1M 0 811 404 140
4WRPE 6 E 32SJ–2X/G24K0/A1M 0 811 404 141
4WRPE 6 W 08SJ–2X/G24K0/A1M 0 811 404 145
4WRPE 6 W 18SJ–2X/G24K0/A1M 0 811 404 142
4WRPE 6 W 18SJ–2X/G24K0/F1M 0 811 404 146
4WRPE 6 W 32SJ–2X/G24K0/A1M 0 811 404 143
4WRPE 6 W 32SJ–2X/G24K0/F1M 0 811 404 147
