Thickness 5mm Carbon Steel C Channel Galvanized Mild Steel U Channel
Price:
USD 860 - 1800 Per Ton
MOQ:
1 Ton
Delivery Time:
7-15 days
Brand:
HUIJIAN
Product Description
Q235b Carbon Steel U Metal Channel 100*50*5mm 25mm X 50 Mm X Thickness 5mm
Product Description
Size |
50*37*4.5-400*104*14.5 |
Item type |
Channel Steel |
Length |
1-12m, or custom |
Material |
Q195,Q215,Q235B,Q345B, S235JR/S235/S355JR/S355 SS440/SM400A/SM400B |
Technique |
Hot rolled |
Application |
structure building, construction |
Surface treatment |
Galvanized, coated or custom |
Grade |
Mild steelcarbon steelstainless steel |
MOQ |
1ton |
trademark |
HUIJIAN |
Specification:
| Size | h(mm) | b(mm) | Thickness(mm) | Density(kg/m) |
| 5# | 50 | 37 | 4.5 | 5.438 |
| 6.3# | 63 | 40 | 4.8 | 6.634 |
| 8# | 80 | 43 | 5 | 8.045 |
| 10# | 100 | 48 | 5.3 | 10.007 |
| 12# | 120 | 53 | 5.5 | 12.059 |
| 14A# | 140 | 58 | 6 | 14.535 |
| 14B# | 140 | 60 | 8 | 16.733 |
| 16A# | 160 | 63 | 6.5 | 17.24 |
| 16B# | 160 | 65 | 8.5 | 19.752 |
| 18A# | 180 | 68 | 7 | 20.174 |
| 18B# | 180 | 70 | 9 | 23 |
| 20A# | 200 | 73 | 7 | 22.637 |
| 20B# | 200 | 75 | 9 | 25.777 |
| 22A# | 220 | 77 | 7 | 24.999 |
| 25A# | 250 | 78 | 7 | 27.41 |
| 25B# | 250 | 80 | 9 | 31.335 |
Company Introduce
Shandong Huijian Metal Materials Co., Ltd. is a new modern private enterprise integrating R&D, production and export. The company is located in Liaocheng, Shandong, a national excellent city known as (Jiangbei Water City), with a registered capital of 60 million yuan, covering an area of more than 100 acres, a construction area of 20,000 square meters, and more than 100 employees. The company has advanced production equipment and Mature technology, but also has a high-quality professional management and technical personnel team. The company has passed the international quality management system ISO9001: 2000 certification.
FAQ
Q:What is a metal U channel?
U channels are mainly used for two purposes: structural metal channels and architectural channels. Most metal channel sizes are available in full length and custom cut lengths.
U channels are mainly used for two purposes: structural metal channels and architectural channels. Most metal channel sizes are available in full length and custom cut lengths.
Q:Are C channel and U channel the same?
Steel channel has been classified into "C" and "U" types depending on its outlook. Hence there are two standards to show the channel dimensions - UPE & UPN. UPE is for the C channel steel with parallel flanges while UPN for the U channel steel with tapered flanges.
Steel channel has been classified into "C" and "U" types depending on its outlook. Hence there are two standards to show the channel dimensions - UPE & UPN. UPE is for the C channel steel with parallel flanges while UPN for the U channel steel with tapered flanges.
Q:What is U channel made of?
U channels can be made from a variety of metals to suit any architect's or engineer's aesthetic needs: Stainless steel U channel trim. Aluminum U channel trim.
U channels can be made from a variety of metals to suit any architect's or engineer's aesthetic needs: Stainless steel U channel trim. Aluminum U channel trim.
What is U channel used for?
The U-channel is a metal rail that is used to secure glass panels to the floor, ceiling, or wall. U-channels reduce the total cost of your frameless shower because the glass sits securely in the channel rather than instead of requiring the drilling and notching of clips.
The U-channel is a metal rail that is used to secure glass panels to the floor, ceiling, or wall. U-channels reduce the total cost of your frameless shower because the glass sits securely in the channel rather than instead of requiring the drilling and notching of clips.
Q:What is U channel used for?
The U-channel is a metal rail that is used to secure glass panels to the floor, ceiling, or wall. U-channels reduce the total cost of your frameless shower because the glass sits securely in the channel rather than instead of requiring the drilling and notching of clips.
The U-channel is a metal rail that is used to secure glass panels to the floor, ceiling, or wall. U-channels reduce the total cost of your frameless shower because the glass sits securely in the channel rather than instead of requiring the drilling and notching of clips.
