Highland High Pressure HPV110 Hydraulic Pump With 1 Year Warranty
Highland High Pressure HPV110 Hydraulic Pump With 1 Year Warranty
Product Description:
Highland Hydraulic Piston Pump is a crucial device in a hydraulic system. It relies on the up-down movement of Highland plunger within a cylinder to change the volume of the sealed working chamber, allowing it to suck in and pressurize oil. Highland Plunger pumps possess a wide array of benefits, such as high rated pressure, small structure, high efficiency, and convenient flow adjustment. Their versatility makes them widely used in many instances where high pressure, large flow, and adjustable flow are required.
Features:
- Our hydraulic axial piston variable displacement pumps are designed with engineering excellence and ease of use in mind. Tapered roller bearings are used in these Variable Axial Piston Pumps, allowing them to handle heavy external axial forces.
- The pumps can be connected with other additional pumps, and when they are mechanically operated, the Servo displacement controls the angle of the swash plate, which adjusts the pump displacement. When the control handle is released, the swash plate returns to its zero position, and flow is reduced to zero.
- The shaft oil seals in hydraulic pumps continues to hold, even when the temperature is low and the case pressure is high. The Servo valve of piston pump can connect the regulators and remote control systems, and these pumps can be easily maintained and disassembled with standard tools. All components are replaceable.
Technical Parameters:
| HPV Series Technical parameter | ||||||||
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Applications:
Hydraulic piston pumps are widely used in applications which require high-pressure, high-flow, and high-power systems, such as agricultural machinery, construction machinery, mining and metallurgical machinery, and ships. Furthermore, this type of pump plays a key role in the petroleum exploration and development, petrochemical, pharmaceutical, atomic energy science, environmental science, process equipment, experimental equipment, aerospace and shipbuilding.
FAQ:
- Q: What is the Brand Name of the Hydraulic Piston Pumps?
A: The Brand Name is Highland. - Q: What is the Model Number of the Hydraulic Piston Pumps?
A: The Model Number is HPV110. - Q: Where is the Hydraulic Piston Pumps made?
A: The Hydraulic Piston Pumps is made in Dezhou, China. - Q: What kind of certification does the Hydraulic Piston Pumps have?
A: The Hydraulic Piston Pumps has a patent certificate. - Q: What is the minimum order quantity for the Hydraulic Piston Pumps?
A: The minimum order quantity is 5 sets.
