SQZ Series Zinc Alloy Ball Joint Rod Ends Bearings(SQZ14RS SQZ14RS-1 SQZ16RS SQZ16RS-1 SQZ18RS SQZ20RS SQZ22RS)
Ball joints with metric and inch threads are commonly used on control linkages in automotive, marine, and construction and industrial equipment applications.
There are DIN,SAE and ISO standard ball joints, you can consult us in regarding these dimensional and technical data.
Technical specification
Material,
Housing, High strength zinc alloy;
Ball, bearing steel GCr15,equivalent to steel SAE52100 ;
Shank, alloy steel 40Cr;
Dust Cover, NBR rubber
Left hand thread, please add suffix 'L',e.g. SQZ16LRS
| Bearing No. | d | d1 | d2 | d3 | l1 | l2 | S1 | L | L1 | L2 | L3 | D1 | D2 | D3 | S2 | a | Load ratings KN |
Mass kg |
| SQZ5RS | 5 | M5x0.8 | 9 | 20 | 8 | 11 | 7 | 46 | 24 | 4.0 | 12 | 9 | 11 | 17 | 9 | 15 | 2.8 | 0.025 |
| SQZ6RS | 6 | M6x1.0 | 10 | 20 | 11 | 12.2 | 8 | 55.2 | 28 | 5.0 | 15 | 10 | 13 | 20 | 11 | 15 | 3.7 | 0.041 |
| SQZ8RS | 8 | M8x1.25 | 12 | 24 | 12 | 16 | 10 | 65 | 32 | 5.0 | 16 | 12.5 | 16 | 24 | 14 | 15 | 5.8 | 0.075 |
| SQZ10RS | 10 | M10x1.25 | 14 | 30 | 15 | 19.5 | 11 | 74.5 | 35 | 6.5 | 18 | 15 | 19 | 28 | 17 | 15 | 8.4 | 0.120 |
| SQZ10RS-1 | 10 | M10x1.5 | 14 | 30 | 21 | 19.5 | 11 | 80.5 | 35 | 6.5 | 18 | 15 | 19 | 28 | 17 | 15 | 8.4 | 0.120 |
| SQZ12RS | 12 | M12x1.25 | 17 | 32 | 17 | 21 | 15 | 84 | 40 | 6.5 | 20 | 17.5 | 22 | 32 | 19 | 15 | 11.0 | 0.180 |
| SQZ12RS-1 | 12 | M12x1.75 | 17 | 32 | 24 | 21 | 15 | 91 | 40 | 6.5 | 20 | 17.5 | 22 | 32 | 19 | 15 | 11.0 | 0.180 |
| SQZ14RS | 14 | M14x1.5 | 19 | 38 | 22 | 23.5 | 17 | 103 | 45 | 8.0 | 25 | 20 | 25 | 36 | 22 | 11 | 15.0 | 0.270 |
| SQZ14RS-1 | 14 | M14x2.0 | 19 | 38 | 28 | 23.5 | 17 | 109 | 45 | 8.0 | 25 | 20 | 25 | 36 | 22 | 11 | 15.0 | 0.270 |
| SQZ16RS | 16 | M16x1.5 | 22 | 44 | 23 | 25.5 | 19 | 112 | 50 | 8.0 | 27 | 22 | 27 | 40 | 22 | 11 | 15.0 | 0.360 |
| SQZ16RS-1 | 16 | M16x2.0 | 22 | 44 | 29 | 25.5 | 19 | 118 | 50 | 8.0 | 27 | 22 | 27 | 40 | 22 | 11 | 15.0 | 0.360 |
| SQZ18RS | 18 | M18x1.5 | 23 | 45 | 25 | 31 | 20 | 130.5 | 58 | 10.0 | 32 | 25 | 31 | 45 | 27 | 11 | 19.0 | 0.540 |
| SQZ20RS | 20 | M20x1.5 | 27 | 50 | 25 | 29 | 24 | 133 | 63 | 10.0 | 38 | 27.5 | 34 | 45 | 30 | 7.5 | 19.0 | 0.570 |
| SQZ22RS | 22 | M22x1.5 | 27 | 52 | 26 | 33 | 24 | 145 | 70 | 12.0 | 43 | 30 | 37 | 50 | 32 | 7.5 | 23.0 | 0.760 |
