Special Ball Socket With Slit (FG1001 FG1002 FG1003 FG1004 FG1301)

DIN 71802 threaded ball joint linkages consist of a DIN 71805 ball socket and a DIN 71803 ball stud.A/B/C type without safety clip on the ball housing

There are Angle Joints DIN71802,Stainless Steel Angle Joint DIN71802,Hexagonal Ball Joints DIN71802,Angle Joints-Long version,Axial Joints similar to DIN71802,Ball Socket DIN71805,Ball Stud DIN71803,Special Ball Socket with slit and customized types.

Material:
Housing: Carbon steel.
Clip: Spring steel
Surface Treatment: Phosphatized and oiled
Optional: Galvanized, passivated in white-blue or black.
Dimensions are in mm.

Part No.	Ball Dia.	length to the center of the ball (a)	Thread	Depth of Thread e	Radial Trigger Force	Axial Trigger Force
FG1001	10	18	M6	≥8	≥1200	≥3500
FG1002	10	18	M8	≥8.5	≥1200	≥3500
FG1003	10	19	M6	≥8.5	≥1200	≥3500
FG1004	10	25	M6	11.5	≥1200	≥3500
FG1301	13	30	M8	14
FG1302	13	25	M8	9
