YJJ MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor

Product Description:

MPX5700DP Textile Equipment Differential Pressure Absolute Pressure 700kpa Analog 5V Pressure Sensor

Features:

MPX5700DP series piezoresistive sensor is an advanced single crystal silicon sensor. This sensor has A wide range of applications and is particularly suitable for those applications that adopt microcontrollers or microprocessors with A/D inputs. This patented unit sensor combines advanced micro-mechanical technology, thin-film metallization and bipolar processing to provide an accurate high-level analog output signal proportional to the applied pressure.

Characteristics

The error rate within the range of 0℃ to 85℃ is 2.5%

2. It is applicable to systems based on microprocessors or microcontrollers

3. Provide differential pressure and gauge pressure configurations

4. Patented silicon shear stress-strain gauge

5. Durable epoxy one-piece molded components

Brand: Frees

Product type: Board computer interface pressure sensor

Working pressure: 102 psi(range 700Kpa)

Pressure type: Differential pressure

Accuracy: 2.5%

Installation style: Through Hole

Port type: No Ports

Packaging: Unibody 6-pin

Working power supply voltage: 5 V

Operating temperature: + 125 ° C

Minimum operating temperature: -40 ° C

Working power supply current: 7 mA

Output voltage: 4.7V

Packaging: Tray

Series: MPX5700

Packaging quantity: 125

Voltage: 5.25V

Voltage - Minimum: 4.75V

Weight: 1.865 g

Specifications:
