Integrated Humidity Sensor HIH-5031-001 HIH5031-001 for Meteorological Stations and Equipment

                  Integrated Humidity Sensor HIH-5031-001 HIH5031-001 for Meteorological Stations and Equipment

Key Features:

• Low Voltage Operation: Works from 2.7 VDC to 5.5 VDC, optimized for 3 V battery-powered systems.
• Ultra-Low Power Consumption: Typical operating current of only 200 µA.
• Condensation Resistance: Factory-fitted with a hydrophobic filter and protected housing, enabling reliable use in high-humidity/condensing environments.
• High Accuracy: ±3% RH accuracy (11%–89% RH range).
• Wide Sensing Range: 0% to 100% relative humidity (RH).
• Fast Response: 5-second response time.
• Near-Linear Analog Voltage Output: Directly readable by microcontrollers.
• SMD Package: 3-pin surface-mount design (tape and reel compatible) for automated assembly.
• Robust Construction: Resists condensation, dust, dirt, oils, and common chemicals.
• Stable Performance: Low drift, long-term stability.
• Temperature Range: -40°C to +85°C.

Typical Applications:

• HVAC & Building Automation: Thermostats, humidifiers/dehumidifiers, air handlers.
• Medical Devices: Incubators, sleep apnea equipment, hospital HVAC.
• Industrial: Air compressors, process control, drying equipment.
• Consumer & Commercial: Refrigeration (transport/storage), telecom cabinets, office automation.
• Battery-Powered Devices: Portable meters, weather stations, wireless sensors.
• OEM Assemblies: High-volume, cost-sensitive integrated products.
