Multifunctional Opt Rf Nd Yag IPL laser 3 In 1 Hair Removal Tattoo Removal Machine
Nd Yag Laser IPL Opt Rf 3 In 1 Multifunctional Hair Removal Tattoo Removal Machine
Light energy performance
1. Single pulse energy: Jm ≥ 2000mj
2. Laser output instability: S ≤ ± 15%
3. Laser output energy reproducibility: Rj <10%
4. Output energy and energy display error: ≤ ± 20%
5. Surgery spot diameter: 1-4nm range continuously adjustable
6. Spot positioning focusing accuracy: the error ≤ ± 0.5mm
Technical Parameter
| IPL system | |
| Handle mode | Filters handle, sapphire handle and high power handle |
| Spot size: | 8*40mm2 or 15*50mm2 |
| Energy density: | 1-20J/cm2 |
| Pulse frequency: | 1~4S, adjustable |
| Pulse number: | 1~6, adjustable |
| Pulse space: | 05~99ms, adjustable |
| Sub-pulse width: | 0.1~9.9ms, adjustable |
| Handle cooling temperature: | -10°C~0°C, adjustable |
| Power: | 2000W (Elight ) ; 1000W (Laser) |
| Lamp longevity: | 400,000shots (IPL) 1,000,000shots(Laser) |
| Language | English,Spanish,France .Italian ,German,Chinese |
| RF system | |
| RF frequency | 10MHZ |
| Energy density: | 1-20J/cm2 |
| Output mode: | Bipolar |
| Energy | 2~300J, adjustable |
| Handle cooling temperature: | -10°C~0°C, adjustable |
| Cooling system: | Air + Water + Semi-conductor cooling |
| Screen | 8.4 inch true color touch screen |
| Power supply | 110/240V+10% 60/50Hz |
| Size | 75*48*120cm |
| Weight | 69kg |
| laser system | |
| Laser wavelength | 1064nm/532nm/1320nm |
| Pulse Energy | 2000MJ |
| Width of pulse | 10-20ns |
| Frequency | 1~10Hz |
| Spot Size | 2~10mm |
| Cooling system | Radiator, air+water-cooled |
| Light source | 220V/110v 50Hz/60Hz |
Scope of application
1)mild, stubborn chloasma treatment
2) deep pigmentary lesions, such as Ota, blue mole
3)superficial pigmented nevus, such as freckles, age spots and so on
4)eliminate all kinds of color tattoos and tattoo, pattern eyeliner and so on
