45° Helix Angle Gear Spline Shaft Alloy Steel With Ra0.4 Roughness
Product Description:
Gear Spline Shaft is a product designed for high-precision transmission. It is manufactured using the forging process, featuring a pressure angle of 20° and axial runout of ≤0.03mm. The surface is polished, and the lead accuracy is guaranteed to be ≤0.02mm. This product is perfect for applications that require precision and durability. It is a reliable and efficient solution for a variety of industrial applications. Gear Spline Shaft is suitable for high-performance transmission, providing superior performance, precision, and reliability. With its durable construction, it is designed to withstand the toughest conditions. Gear Spline Shaft is the perfect choice for any project that requires precision and quality.
Features:
- Product Name: Spline Gear Shaft
- Lead Accuracy: ≤0.02mm
- Roughness: Ra0.4
- Helix Angle: 45°
- Backlash: 0.1-0.5mm
- Center Distance: Customized
Technical Parameters:
| Parameters | Value |
|---|---|
| Radial Runout | ≤0.02mm |
| Number of Teeth | 10-200 |
| Roughness | Ra0.4 |
| Center Distance | Customized |
| Lead Accuracy | ≤0.02mm |
| Helix Angle | 45° |
| Surface Treatment | Polishing |
| Pressure Angle | 20° |
| Processing Type | Forging |
| Diametral Pitch | 8-64 |
Applications:
Spline Gear Shaft is a high-performance gear shaft developed by OEM with custom specifications. Made from alloy steel, it is designed to provide high durability and reliability in a wide range of applications. The gear shaft has a backlash of 0.1-0.5mm, an involute tooth profile, and a radial runout of ≤0.02mm. It also has a diametral pitch of 8-64 for precise and efficient power transmission. With a minimum order quantity of 500 and a price of 25, OEM provides excellent cost-effectiveness and convenience. Furthermore, with a supply ability of 5000Pcs/Month, OEM ensures that customers can get their orders quickly and in good condition with the packaging details of Plywood Crate and a delivery time of 50 Days. OEM also offers payment terms of T/T to make transactions secure and satisfactory.
Customization:
Our Gear Spline Shafts are made with the highest quality materials and components, guaranteeing superior performance. Our Gear Spline Shafts are made with Brand Name: OEM, Model Number: CUSTOM, Lead Accuracy: ≤0.02mm, Backlash: 0.1-0.5mm, Number of Teeth: 10-200, Processing Type: Forging, Center Distance: Customized. We guarantee top rate quality and performance.
Our Gear Spline Shafts are available with the following features:
- Place of Origin: CHINA
- Certification: QC
- Minimum Order Quantity: 500
- Price: 25
- Packaging Details: Plywoode Crate
- Delivery Time: 50 Days
- Payment Terms: T/T
- Supply Ability: 5000Pcs/Month
We are committed to providing our customers with the highest quality Gear Spline Shafts at the best possible price. If you are looking for superior quality and a reliable supplier, please contact us today. We look forward to hearing from you soon.
Packing and Shipping:
Our Spline Gear Shafts are securely packaged and shipped to ensure a safe delivery. To ensure the optimal safety of our products, we use high-quality, recyclable materials to protect the product. The following are the steps we take for packaging and shipping our Spline Gear Shafts:
- We wrap the shafts in protective plastic.
- We place the shafts in a strong, cardboard box.
- We include additional padding and cushioning materials to minimize any potential for damage during shipping.
- We seal the box with industrial-grade tape.
- We label the box with clear delivery information.
- We ship the package to the customer via a reputable carrier.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
