Industrial Brake Hose Crimping Machine with 980T Crimping Force, 14-167mm Crimping Range, and 31.5Mpa System Pressure
Price:
Contact Us
MOQ:
1 Set
Delivery Time:
2 - 7 Working Days
Brand:
MENSION
Product Description
Brake Hose Crimping Machine Industrial Hose Crimper Finn Power Swager P32 Crimper
Product Overview
The MS-E180 brake hose crimper machine is renowned for its exceptional crimping force, making it the ideal solution for large-size and high-pressure pipes and tubes. Equipped with a FINN POWER quality dial, this machine achieves precision accuracy of 0.01mm.
Main Features
- Unique valve connect system for high stability
- One-piece hydraulic head design prevents oil leakage
- Solenoid valve with high hardness spool for extended service life
- Heat-treated die base for enhanced durability
Technical Specifications
| Model | MS-E180 Brake Hose Crimping Machine |
|---|---|
| Crimping Range | 14 - 167 (mm) |
| Crimping Force | 980 (T) |
| Hose Size | 1/4 - 4 (inch) |
| Max. Opening | 45 (mm) |
| Die Sets | 18 |
| Die Set Type | 32 180 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.01 (mm) |
| Control | MS |
| Standard Voltage | 380 (V) |
| Motor Power | 7.5 (KW) |
| Length | 800 (mm) |
| Width | 650 (mm) |
| Height | 880 (mm) |
| Weight | 510 (KG) |
E180 Crimper Die Sets
| Die No. | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8mm | 55 |
| 8* | 8 - 10mm | 55 |
| 10* | 10 - 12mm | 55 |
| 12* | 12 - 15mm | 55 |
| 15 | 15 - 18mm | 55 |
| 18 | 18 - 21mm | 55 |
| 21 | 21 - 24mm | 55 |
| 24 | 24 - 27mm | 55 |
| 27 | 27 - 33mm | 55 |
| 33 | 33 - 39mm | 75 |
| 39 | 39 - 45mm | 75 |
| 45 | 45 - 51mm | 90 |
| 51 | 51 - 57mm | 90 |
| 57 | 57 - 66mm | 100 |
| 66 | 66 - 73mm | 110 |
| 73 | 73 - 90mm | 110 |
| 90 | 90 - 96mm | 120 |
| 96 | 96 - 102mm | 120 |
| 102 | 102 - 108mm | 120 |
| 108 | 108 - 114mm | 120 |
| 114 | 114 - 123mm | 120 |
| 123 | 123 - 136mm | 120 |
Important Notes
- * indicates non-standard die sets
- Customized die sets are available upon request
- Special voltage options available: 110V, 208V, 240V, 415V
