Industrial Wall Hung Electric Boiler Corrosion Resistant For Winter Heating
Wall Mounted Electric Boiler 8kw Electric boiler for heating in winter Electric heating
Wall Mounted Electric Boiler Product Parameters:
| NO. | Product model | Unit | LC-B-6kw | LC-B-8kw | LC-B-10kw | LC-B-12kw | LC-B-15kw |
| 1 | Rated power | KW | 6 | 8 | 10 | 12 | 15 |
| 2 | Rated current | A | 27.3 | 36.4 | 45.5 | 48.2 | 52.8 |
| 3 | Heating area | ㎡ | 60-80 | 80-100 | 100-120 | 120-140 | 150-180 |
| 4 | input voltage | 50HZ | 220V | 220V | 220V | 220V/380V | 220V/380V |
| 5 | Minimum flow of water pump configuration | L/min | 15 | 15 | 20 | 20 | 25 |
| 6 | Hot water yield 50 ℃ | L/min | 5.62 | 3.75 | 4.69 | 5.62 | 6.9 |
| 7 | Design thermal efficiency | ℃ | 98% | 98% | 98% | 98% | 98% |
| 8 | Maximum water temperature | ℃ | 85 | 85 | 85 | 85 | 85 |
| 9 | Low temperature protection temperature | ℃ | 5 | 5 | 5 | 5 | 5 |
| 10 | Overall dimension (length * width * height) | mm | 360*170*630 | 360*170*630 | 360*170*630 | 360*170*630 | 360*170*630 |
| 11 | Water inlet and outlet interface | DN | 32 | 32 | 32 | 32 | 32 |
Product Details:
Why choose us ?
Service Life Of Wall Mounted Electric Boiler:
The wall mounted electric boiler adopts industrial grade electromagnetic, high-temperature resistant wire, corrosion-resistant, and the heating pipe is not easy to scale, with a service life of more than 15 years.
How To Maintain The Wall Mounted Electric Boiler:
Electromagnetic induction heating: when working, the core part of the heating is a fixed magnetic field, and the water is magnetized after passing through. The magnetized water structure makes the system maintenance free.
