Inconel 800 Wire Mesh Demister Pad Resistance To Acids For Petrochemical

Inconel 800 Wire Mesh resistance to acids Demister Pad

Inconel 800 Demister Pad Information

The Incoloy 800 Mesh Mist Eliminator is as effective in many water environments as it is at high temperatures. It has the ability to resist erosion and other decays usually associated with aquatic environments. Its strength and resistance give Incoloy 800 a versatility not found in many alloys. It has been used in a variety of industries and has become a mainstay in high temperature, high exposure applications.

Inconel 800 Demister Pad Corrosion resistance:

Incoloy 800 Mesh Demister is generally free from chloride stress corrosion cracking and sensitization induced intergranular corrosion. The alloy can be used in seawater. Incoloy 800 mist eliminators have similar acid resistance to austenitic stainless steels. It has excellent resistance to both oxidizing and non-oxidizing salts, with the exception of halide salts, which may exhibit pitting corrosion.
Technical data:
Typical limit droplet size = 3 microns
Mesh Pad Speed = 450 fpm
Typical mesh pad pressure drop STP = 0.4wc
Mesh Pad + Contour Eliminator Speed = 1100 fpm
Typical pressure drop for Mesh Pad + Profile demister combination = 0.6wc
Available Specifications:
Diameter: 1000-4100mm
Thickness: 100-200mm
Filtration rate: 98%-98.9%

Selected Demister Pad Type Of Demister

Demister Pad Material:

Stainless steel:304,304L,316,316L etc.

Plastic:PP,PE,PVC,PVDF.

Also, produce special material according to customer's request.

 Demister Pad Features:

Excellent low-temperature resistance. It can also play well at 100 C.

Excellent chemical stability. It resists most acid-base solvents.

Water absorption can be small.

Good electrical insulation performance.

Heat resistance and aging. It can last a very long service life.

Demister Pad Application

Wire mesh separators are used for example:

- to purify gasses;

- to eliminate liquids that could damage the production processes;

- to prevent problems to the plant structures;

- to prevent emissions dangerous to the environment;

- to recover expensive liquids

Company Profile

Anping County Hardware Mesh Products Co., Ltd. is located in Anping County, Hebei Province, known as the "Hometown of Chinese Wire Mesh". The company is a dedicated manufacturer of wire mesh demisters. The company has more than 90 sets of knitted mesh equipment. The wire mesh demister is the main product of our company. Most of our employees are operation, maintenance, and installation personnel with practical experience, who can provide customers with the required engineering consultation and installation of tank filtration. solution.Nearly 20 years of experience producing mist eliminator mats, knitted wire mesh, and other packaging materials.

We have ISO9001 certification and a strict quality control system in the QC department of the enterprise.

We claim that all mist eliminator pads our customers receive are qualified and perform flawlessly. We have different specifications.

The filtration fineness can reach 3μm~5μm. In addition to standard and popular sizes, we can also customize specific applications according to customer needs.

Through continuous on-the-spot inspections, personal exchanges and cooperation with customers, and comprehensive discounts and technical support, we have won strong customer support and praise during the company's development.

The company's performance has maintained an annual output value growth rate of 30-40. Our employees pursue the policy of "enterprising, truth-seeking, rigorous and united", continue to develop and innovate, take technology as the core, and wholeheartedly provide you with cost-effective products, high-quality engineering design, and services.

Welcome customer consultation and I sincerely look forward to cooperating with you!
