Automatic Spraying Wet Alarm Valve QT450 Wet Alarm Check Valve 80mm

Automatic Spraying ZSFZ Wet Alarm Valve

 I. Overview

    The wet alarm valve is connected with the delayer, hydraulic alarm bell, sprinkler head, fire water supply system, etc. to form an automatic sprinkler system. It is an important alarm control valve in the automatic sprinkler system.

2.Main overall dimensions

 3. Use and maintenance

    Fire gate valves are often used in automatic sprinkler fire pipeline systems, rotating handwheels to control the opening and closing of water sources in water supply pipelines.

4. Installation:

(1) Handwheels, handles and transmission mechanisms are not allowed to be used for lifting, and collisions are strictly prohibited.

(2) Before installation, check whether the product model, tag and specification are consistent, and check whether the parts of the whole machine are defective and loose.

(3) Before installation, the pipeline should be cleaned, and there should be enough straight pipe section at the valve inlet, and equipped with a filter.

(4) The installation site should consider the comprehensive personnel and equipment, even if it is operated, it is conducive to disassembly and maintenance.

(5) The signal box is connected to the fire protection system circuit.
