7 Inch 10000psi Well Completion Tools
Price:
USD 1-10000/set
MOQ:
1 set
Delivery Time:
30-50 days
Brand:
ZZ TOP OIL TOOLS
Product Description
Squeeze Packer / Drillable Bridge Plug / Cement Retainers 7"x 10000psi working pressure
Product Overview
The Squeeze Packer is a high-temperature/high-pressure sliding-valve used in remedial cementing operations. It can also function as a drillable bridge plug and cement retainer. Constructed from cast iron, brass, aluminum, and rubber for optimal drillability.
Key Features
- Controls flow and pressure differential in either direction
- Allows pressure testing of workstring
- Slips designed for all grades of casing
- Top-drilling bridge plug conversion capability
- Pressure venting feature for safer drilling/milling
Technical Specifications
| Parameter | Value |
|---|---|
| Applicable Casing size | 6 5/8"17-24# 7" 20-38# 7 5/8" 45.3-55.3# 7 3/4"53.52# |
| Max. Casing ID | 164.1mm |
| Max. OD | 139.7mm |
| Length | 802mm |
| Max. Differential Pressure | 10000psi |
| Working Temperature | -29°C~120°C |
| Tension Sleeve Value | 40000lbs/25000lbs/30000lbs |
